m INCLUDED WITH OPERATOR:
Check package to make sure it contains the following items.
STANDARD GATE OPENER
l 1-Model AGS 900 gate operator
l 2-Mounting Posts 2" Diameter x 30"
l 2-Gate/Chain Brackets, U-Bolt type
l 2-U-Bolts Round
l 2-U-Bolts Square
l 1-Chain #41 x 25 ft
l 2-Master Links #41
l 2-Chain Bolts
l 2-Self Tapping Screws
l 1-Hex Key for Cover
l 2-Manual Release Keys
BATTERY BACK-UP ONLY
l 1-Burial cable, 10 ft
l 1-Charger, 12 Volt
l 1-Battery, 12 Volt (installed)
SOLAR ONLY
l 3-Pipe sections, 1" X 24"
l 2-Pipe couplings, 1"
l 1-Solar Panel Assembly
l 5-Lock Rings
l 2-Batteries, 12 Volt (installed)
(See parts identification.)
General Information
mm
mm
m POWER REQUIREMENT:
There are three possibilities for supplying power to the AGS 900 gate operator. The standard
power supply version is made to connect directly to 115 Volt, 5 Amp power source and is available for
standard capability and full systems capability models. This power supply must be at or near the gate
operator location. Because of the low current draw, 115 Volt power may be run as far as 1000 feet
with 12 gauge wire from the main breaker panel and can be run much farther with larger wire.
Another possibility for supplying power to the operator is with the low voltage battery back-up version
of the AGS 900. To supply power to the AGS 900 battery back-up, wire as small as 16 gauge can be
run as far as 300 feet from a charger that is plugged in remotely. Because the power is low 12 Volt
DC, the wire can be direct burial wire which eliminates the need for expensive conduit runs. The other
possibility for supplying power to the AGS 900 is with the Solar power version of the operator. The
Solar model does not require any power to be run because the operator and solar power supply are
self contained. The panel may be placed several hundred feet from the operator if this is necessary
to achieve maximum sunlight conditions.
mm
mm
m MOUNTING:
There are two ways to mount the AGS 900 operator. One way to mount the operator is to
attach it with bolts to a concrete surface using the optional concrete mounting stand and sleeve
anchors. In some cases there will already be an existing concrete surface or pad available to bolt the
operator to. If there is no existing concrete surface or pad, it is very easy to fashion one so that the
operator can be bolted down at a later time using sleeve anchors. The other way to mount the AGS
900 operator is directly into the earth with the two 2" X 30" mounting posts that have been provided.
For this installation the posts are attached to the operator, one post hole is made in the earth and
then the operator with posts attached is set in place. The cement can then be poured into the post
hole and will dry within minutes if concrete accelerator is used. The operator can be put into full
operation the very same day.
