pg 8
PART # QNTY. QNTY.
001 1 SUBSTRATE (FRAME)
002 1 BEARING PLATE
003 2 SIDE PLATE
004 1 COVER
005 1 FIRE WALL
006 1 GEAR MOTOR, 12 VDC
007 2 LIMIT NUT
008 1 SPROCKET, DRIVE 41B9, 1/2" BORE
009 1 BUSHING, DRIVE SHAFT 1/2" BORE
010 3 BOLT, HEX HEAD, 5/16"-18 X 3/4"
011 3 WASHER, SPLIT RING, 5/16" ID
012 1 LIMIT GUIDE PLATE
013 1 LIMIT SWITCH MOUNTING PLATE
014 2 LIMIT SWITCH
015 4 SCREW, PAN HEAD PHILLUPS, 6-32 X 1"
016 6 SCREW, SOCKET HEAD CAP, 10-32 X 5/8"
017 6 LOCKNUT, 10-32 STAR LOCK, HEX
018 1 SCREW, SOCKET HEAD CAP, 10-32 X 1"
019 2 LIMIT PLATE COMPRESSION SPRING
020 2 LOCKNUT, 8-32 NYLON INSERT, HEX
021 1 TRANSFORMER (115 V MODELS ONLY)
022 1 CONTROL BOARD (FULL SYSTEMS OPTIONAL)
023 4 HEX STANDOFF, 6-32 X 1/2" F/F
024 4 HEX STANDOFF, 6-32 X 1" M/F (FULL SYSTEMS ONLY)
025 1 PLEXI GLASS COVER (FULL SYSTEMS ONLY)
026 8 SCREW, 6-32 X 3/8" PAN HEAD PHILLUPS
027 1 SPROCKET, IDLER 41B11 3/4" BORE
028 1 BUSHING 5/8" BORE
029 1 HEX BOLT 5/8"
030 2 HEX JAM NUT 5/8"
031
032
033
034
035
036
037
038
039
040
041
042
043
044
045
15 WASHER, SPLIT RING 3/8"ID
15 NUT, 3/8"-16
4 U-BOLT, ROUND
7 HEX BOLT, 3/8"-16
1 RESISTOR, 1 OHM
1 HEX BOLT, 5/16"-18 X 3"
2 FIBER WASHER 3/8" ID
1 HEX NUT, 5/16"-18
1 BRIDGE RECTIFIER, 35 AMP, 800 VOLT
1 LOCK NUT, 8-32 STAR LOCK, HEX
1 CIRCUIT BREAKER, 1.5 AMP
1 KEY SWITCH, MANUAL RELEASE
1 RECEIVER ENCLOSURE
15 WASHER, FLAT 3/8" ID
PART # QNTY. QNTY.
046 3 PLUG 1-3/8"
047 4 PLUG 5/8"
048 2 PLUG 7/16"
049 1 CONDUIT FITTING, 90 DEGREE FLEX
050 2 MOUNTING POST, 2" DIAMETER
051 1 MOUNTING STAND FOR CONCRETE (OPTIONAL)
052 4 SLEAVE ANCHOR, 3/8" X 3"
053 1 RADIO RECEIVER (OPTIONAL)
054 1 FLOAT CHARGER (OPTIONAL)
055 1 BURIAL CABLE (OPTIONAL)
056 1 GATE/CHAIN BRACKET (RIGHT)
057 1 GATE/CHAIN BRACKET (LEFT)
058 2 CHAIN BOLT
059 1 CHAIN #41
060 2 MASTER LINK #41
061 2 SELF TAPPING SCREW (FOR GATE BRACKET)
062 1 SCREW, SOCKET HEAD CAP (FOR COVER)
063 1 NYLON WASHER 3/8" ID FOR COVER SCREW
064 1 ALLEN WRENCH, 5/16"
065 1 AGS 900 LOGO, DIE CAST ZINC
066 1 STICKER, WEATHER
067 1 STICKER, CAUTION
068 1 STICKER, FLAG
069 BATTERY BACK-UP AND SOLAR
070 1 BATTERY, 12 VDC (2 FOR SOLAR)
071 1 BATTERY/RECEIVER ENCLOSURE
072 1 SOLAR PANEL
4 SOLAR PANEL MOUNTING POSTS
074 MODULAR ELECTRICAL CONNECTORS
075
076
077
078
079
080
081
082
083
084
085
086
087
088
089
090
SCREW, PAN HEAD PHILLUPS, 10-32 X 1/2"
4
073
3
Parts Identification continued...
