DEVICE DESCRIPTION
CONTROL PANEL
Control buttons Status indicators
1 Power button
2 Start/Pause
3 Steamer mode
4 Blender/chopper mode
5 Heating mode
6 Sterilization mode
7 Increase time
8 Reduce time
9 Keep warm mode
10 Self-cleaning mode
11 Power ON
12 Blender ON/Chopper ON
13 Steamer ON (2 power modes)
14 Time (minutes and hours)
15 Low water indicator
16 Sterilizer ON
17 Heater ON
9 11 12 13
14
10
15 16 17
8
7
1
2
3
4
5
6
