Ai-Thinker Technology ESP-12F User Manual

ESP-12F User Manual
Shenzhen Ai-Thinker Technology Co., Ltd http://www.ai-thinker.com
9
3. Package information and OEM installation method
The external size of theESP-12F WiFi module is 16mm*17mm*3mm, as is illustrated in Figure 4 below:
Figure 4 Dimensions of ESP-12F WiFi Module
Table 5 Dimensions of ESP-12F WiFi Module
Length
width
Height
PAD Size(Bottom)
Pin Pitch
16mm
24mm
3 mm
1 mm x 1.2 mm
2mm
3.1.
Package information
ESP-12F use a half hole patch package, Module PCB Footprint shown in the following figure:
Figure 5 Module PCB Footprint
