Aim-TTI EX354RD User Manual

3
Ripple & Noise
(20MHz bandwidth):
Typically <2mVrms, <10mVpk-pk, constant voltage mode.
Transient Response:
<200µs to within 50mV of set level for a 5% to 95% load change.
Temperature Coefficient:
Typically <100ppm/°C.
Status Indication:
Output on lamp. Constant current mode lamp.
METER SPECIFICATIONS (Main Outputs)
Meter Types:
Dual 4 digit meters with 14mm (0·56") LEDs. Reading rate 4 Hz.
Meter Resolutions:
10mV, 1mA.
Meter Accuracies: Voltage 0.3% of reading ± 3 digits,
Current 0.5% of reading ± 3 digits.
AUXILIARY LOGIC OUTPUT (EX354RT only)
Voltage:
Variable <1.5V to >5V by front panel control.
Meter Voltage Accuracy:
0.3% ± 4 digits
Current Limit:
5A minimum.
Output Protection: Output will withstand up to 7V forward voltage.
Diode clamp reverse protection for currents up to 3A.
Load Regulation:
<0.5% for 90% load change.
Line Regulation:
<0.1% for 10% line voltage change.
Ripple & Noise
(20MHz bandwidth):
Typically <2mVrms, <10mVpk-pk (CV mode).
Transient Response:
Typically <200µs to within 50mV of set level for a 5% to 95% load
change.
Temperature Coefficient:
Typically <100ppm/ºC.
Status Indication:
UNREG lamp.
GENERAL
AC Input:
110V - 240V AC ± 10%, 50/60Hz. Installation Category II.
Power Consumption:
500VA max.
Operating Range:
+5ºC to +40ºC, 20% to 80% RH.
Storage Range:
−40ºC to + 70ºC.
Environmental:
Indoor use at altitudes up to 2000m, Pollution Degree 2.
Safety & EMC: Complies with EN61010-1 & EN61326-1.
For details, request the EU Declaration of Conformity for this
instrument via http://www.aimtti.com/support (serial no. needed).
Size:
260 x 160 x 320mm (WxHxD).
Weight:
4.3kg
