Adjust seat position and angle
To change the angle and hori-
zontal position of the seat: A.
Use a 5mm Allen wrench to
loosen the seat adjustment
bolt located directly beneath
the seat and above the rear
wheel. Do not completely
remove the bolt. B. Move the
seat backward or forward and
tilt to adjust the angle. For
most riders, a seat position that
is level with the flat ground is
ideal. Do not exceed the limit
marks for minimum and maxi-
mum horizontal movement
Step Twelve
displayed on the seat rail. C.
While holding the seat in the
desired position, use a 5mm
Allen wrench to tighten the
seat angle adjustment bolt to
the recommended torque
value (8Nm).
Check if the key and the battery lock have the same serial number.
Step Thirteen
24
