Align the fixing hole on the top
of the front mudguard with the
threaded hole of the front fork
bracket, place the front light
bracket hole at the back, tight-
en the fixing screw after the
three holes are aligned, and
then tighten the front mud-
guard support rod.
Step Ten
Adjust the saddle to your
desired height. Fully open the
quick release lever. Adjust the
seat post up or down to a com-
fortable height, ensuring that
the seat post is inserted into
the frame beyond the mini-
mum insertion point.
Step Eleven
