AIMS Power SCC20A User Manual

23
SPECIFICATION
SCC20A
SCC30
SCC40
SCC60
SCC80
SCC100
Solar System Voltage
12V/24V
12V/24V/36V/48V
Electrical
PV operating voltage
18~100Vdc@12V
34~100Vdc@24V
15~155Vdc@12V
34~155Vdc@24V
50~155Vdc@36V
60~155Vdc@48V
Max. PV open circuit
voltage
100Vdc
155Vdc
Rated PV input
12V 400W
24V 800W
12V 500W
24V 1000W
36V 1500W
48V 2000W
12V 800W
24V 1700W
36V 2400W
48V 3400W
12V 1200W
24V 2400W
36V 3600W
48V 4800W
12V 1400W
24V 2800W
36V 4200W
48V 5600W
Max. charging current
20A
30A
40A
60A
80A
100A
Max. DC load current
30A
40A
60A
Self-Consumption
＜
2W
＜
4W
Conversion Efficiency
97%
97%
97.5%
98%
98.5%
Protection
Overload, short circuit, high voltage, high temperature protection
Battery Charging
Battery Type
Gel, Sealed, AGM, Flooded, Lithium, User define
Charging Algorithm
3-stage: Bulk, Absorption, Float | 4-stage: Bulk, Absorption, Float, Equalize
Bulk charge voltage
Sealed:14.4V AGM Gel:14.2V Flooded:14.6V User define:10-15V
Float charge voltage
Sealed/Gel/AMG:13.7V Flooded:13.6V User define :10-15V
Equalize charge voltage
Sealed:14.6V AGM:14.8V Flooded:14.8V User define :10-15V
Low voltage
reconnect voltage
12.5V
Low voltage
disconnect voltage
10.5V (10.5~12.5 Adjustable)
Temperature compensation
-5mV/
℃
/2V with BTS(Optional)
Communication
Communication Port
NONE
RS485
Mechanical
Net weight
4.7 lb
4.7lb
9 lb
17 lb
20 lb
21 lb
Gross weight
6 lb
6 lb
12 lb
21 lb
24 lb
26 lb
Dimensions
8.25x7.5x3.25” 8.25x7.5x3.2” 11x8.25x3.75”
14.5x10.5x4.5”
17x10.5x5” 18.25x10.5x5”
Packing box
13x13x4.5”
13x13x4.5”
18x12x6”
23x16x9”
23x16x9”
23x16x9”
Cooling
Heatsink cooling
Enclosure
IP43
Environment
Ambient Temperature
-25~60
℃
(Derating from 45
℃
) | -11 F to 140 F
Storage Temperature
-40
℃
~+80
℃ |
-140 F to 176 F
Humidity
100% non-condensing
Warranty
Two Year
