Aiphone IX-DV Owners & Installation Manual

- 13 -
Wiring Connection
• Insulate and secure unused low-voltage lines and the connector-attached lead wire.
S1 S2 S3 S4 S5 SE
NO1 COM1 NC1 NO2 COM2 NC2
IX-DVFIX-DV IX-SSA, etc
Door Stations
CN1
CN2
+
‒
P
P
S6ES6
CN3
Brown
Red
Orange
Yellow
Green
Blue
Brown
Red
Orange
Yellow
Green
Blue
Brown
Red
Orange
Yellow
Green
Blue
CN4 CN5
＋
24VDC
(AC Power adapter PS-2420)
Pre-installed Emergency button Pre-installed Hearing aid unit
(IX-DVF-L)
(IX-DVF-RA, IX-SSA-RA,
IX-DVF-2RA, IX-SSA-2RA)
−
