- 8 -
Included accessories
IX-DV
IX-DVF, IX-DVF-P, IX-DVF-2RA, IX-DVF-RA, IX-DVF-L, IX-SSA, IX-SSA-2RA, IX-SSA-RA
Status Indicator
Refer to "Operation Manual" for additional indicators not listed.
: Lit : Off
Anchors x 4 Wall-mounting screws x 4 Special screwdriver x 1
Installation Manual × 2 (English,
French)
Notice (IX Manuals and Software) x 1 Option connectors
(6pin x 1, 7pin x 1, 8pin x 1)
Ferrite cores x 2
Chinese RoHS declaration × 1
Back box x 1 Special screws x 4 Special screwdriver x 1
Installation Manual × 2 (English,
French)
Notice (IX Manuals and Software) x 1 Option connectors
(6pin x 1, 7pin x 1, 8pin x 1)
Ferrite cores x 2 Transparent name plates x 2
(IX-DVF-L only)
Chinese RoHS declaration × 1
Status (Pattern) Meaning
Orange flashing Normal flashing Booting
Rapid flashing Device error
Long interval flashing Communication failure
Long irregular flashing Firmware version updating
Long irregular flashing Mounting micro SD card,
unmounting micro SD card
Long irregular flashing Initializing
Blue light Standby
0.75 sec 0.75 sec
0.25 sec 0.25 sec
0.5 sec 4 sec
1
sec
0.25
sec
0.25
sec
0.25
sec
0.25
sec
0.25
sec
2
sec
0.25
sec
0.25
sec
0.25
sec
1
sec
0.25
sec
0.25
sec
0.25
sec
