17
For each programmed output, set the Function on the IXW-MA(A) to Contact Change SIF Event. Each output can
only be assigned to a single station.
Repeat these steps for each output to be programmed. Then, upload settings to all stations to complete the
process (see page 10 for more information).
Only one station can
be assigned to each
IXW-MA(A) output.
Scroll right to the Contact Change SIF Event column. Click
Select Station
to display a list of stations. Select
the signaling station and click
OK
. Click
Update
.
IXW-MA(A) Programming (continued)
Conguring Stations for SIF Signaling
Navigate to Option Input / Relay Output Settings, Relay Output. Relay Output 1 will be displayed by default.
The Display settings menu can be used to switch to other relay outputs.
