JO-DA
Remove the main unit from
the mounting frame by
loosening the locking screws
1
Place " UP" upwards
Mounting screw x 2
(Screw shaft: Ø4.1)
(Slotted Head: Ø8.2 or less
<Back wiring>
Mount the main unit on
the mounting frame,
and fit the front panel on.
Removing the front panel
<Bottom surface>
Screwdriver
Height 3.0mm or less)
(not included)
1-gang box
Main unit
Flathead screwdriver
Tighten
Loosen
83.5 mm
Pry off the front panel with
(3-5/16")
Front panel Main unit
a flathead screwdriver.
2
Fasten the mounting
<Surface wiring>
frame to the wall.
Mounting frame
Mounting screw x 2
83.5 mm
3
Connect wires.
Drainage hole
(Screw shaft: Ø4.1)
(3-5/16")
(Slotted Head: Ø8.2 or less
Height 3.0mm or less)
(not included)
Do not block the holes.
Installation height
(center of the unit)
1,500 mm (5')
Wire slot
Insert a wire from the lower side.
JO-DV
Anchor x 4
4
Fasten the unit to the mounting surface.
(Prepare anchors according to the size of the mounting screws.)
*Use board anchors or concrete plugs as needed.
(not included)
75 mm
3''
50 mm
1
Loosen the special screw
1-31/32''
(The diameter and the depth of the holes on the wall depend on
the anchors suitable for the mounting screws used.)
with the special screwdriver,
150 mm
and remove the front panel.
Vanda resistant
5-15/16''
front panel
3
Connect wires to the unit.
70 mm
2-3/4''
Special
screwdriver
Loosen
(included)
2
Insert the transparent name plate.
1. Peel off the protective seals on the plate (both sides).
2. Fill in the name on the transparent name plate.
Be sure to leave 25 mm (1") of white space on the right
end to account for insertion.
3. Insert the filled-in transparent name plate as below
The unit
(indicated with in diagram).
Mounting screw × 4
(Screw shaft: Ø4.1)
Insert transparent
(Slotted Head: Ø8.2 or less
Height 3.0mm or less)
name plate here.
(not included)
Tighten
25 mm
Drainage hole
5
Replace face plate and tighten
(1")
Special
Do not block the holes.
screw with included special
ABCDEFG
screw
screwdriver.
2 mm (1/8")
JO-DVF
Flush mount back box
(included)
Vandal resistant front panel with the unit attached
110 mm
1
Install the flush mount back box in
4-3/8''
the wall, and then connect the wires to
the unit with the terminal cover open.
180mm
7-3/32''
3
Fasten the front panel to the back
box with the special screws.
Loosen
2
Insert the transparent name plate.
*See above JO-DV for details.
Tighten
Special
screw x 4
45 mm
(included)
Hexagonal wrench (included)
1-25/32''
Transparent name plate
