Service Manual

Table of Contents

Questions and Answers

  • K
    Kim ChristianAug 18, 2025
    What to do if there is a communication failure between the indoor unit and outdoor unit in my Air-Con Air Conditioner?
    • G
      gdavisAug 18, 2025
      If the Air-Con Air Conditioner displays a communication failure between the indoor and outdoor units, check the following: * Ensure the communication cable is securely connected. * Verify the communication cable is not faulty. * Check the connection between the filter board and the outdoor control board, ensuring it is correct and secure. * Check the connection between the filter board and the terminal, ensuring it is correct and secure. * The indoor control board might be faulty. * The PFC board might be faulty. * The power board might be faulty. * The outdoor control board might be faulty.
  • E
    edward24Aug 20, 2025
    What causes current overload protection in Air-Con Air Conditioner?
    • A
      andrew57Aug 20, 2025
      If your Air-Con Air Conditioner is showing current overload protection, it might be due to: * Abnormal fan motor operation. * Dirty condenser and evaporator coils. * Abnormal air inlet or outlet conditions.
  • C
    Carolyn RuizAug 22, 2025
    Why does my Air-Con Air Conditioner show compressor exhaust temperature too high protection?
    • C
      Christopher WalkerAug 23, 2025
      If your Air-Con Air Conditioner is showing compressor exhaust temperature too high protection, it could be due to: * A faulty compressor exhaust temperature sensor. * Insufficient refrigerant in the unit.
  • K
    kristinlopezAug 26, 2025
    What causes compressor shell temperature too high protection in Air-Con Air Conditioner?
    • N
      Nicole Mathis MDAug 26, 2025
      If your Air-Con Air Conditioner is showing compressor shell temperature too high protection, it might be due to: * A loose connection of the compressor exhaust temperature sensor. * Insufficient refrigerant in the unit.
  • J
    jessica05Aug 27, 2025
    What to do if my Air-Con Air Conditioner shows anti-freeze or overload protection?
    • J
      Joseph HughesAug 28, 2025
      If the Air-Con Air Conditioner is experiencing anti-freeze protection during cooling or overload protection during heating, consider the following: * Check if the indoor coil temperature sensor is loosely connected. * The indoor coil temperature sensor might be faulty. * The indoor control board might be faulty. * The refrigerant system might be abnormal.
  • M
    Mrs. Shelley Horn DDSAug 30, 2025
    What to do if the compressor drive is in trouble in my Air-Con Air Conditioner?
    • D
      Douglas SmithAug 30, 2025
      If your Air-Con Air Conditioner's compressor drive is in trouble, possible causes include: * A faulty outdoor drive board. * A faulty compressor. * A faulty outdoor control board.
  • A
    amber25Sep 2, 2025
    Why is the outdoor fan motor locked on my Air-Con Air Conditioner?
    • M
      Melissa ReynoldsSep 2, 2025
      If your Air-Con Air Conditioner's outdoor fan motor has locked rotor protection, check the following: * Ensure the outdoor fan motor connection is secure. * Check for any obstructions blocking the outdoor fan. * The fan motor might be faulty. * The outdoor control board might be faulty.
  • K
    Keith KingSep 4, 2025
    What causes DC compressor start failure in Air-Con Air Conditioner?
    • W
      william41Sep 4, 2025
      If your Air-Con Air Conditioner's DC compressor fails to start, it could be due to: * A faulty outdoor drive board. * A faulty compressor.
  • R
    Rebecca TorresSep 6, 2025
    What to do if the outdoor EEPROM is in trouble in my Air-Con Air Conditioner?
    • S
      Steven GreenSep 7, 2025
      If your Air-Con Air Conditioner's outdoor EEPROM is in trouble, check: * If the EEPROM chip is loose. * If the EEPROM chip is inserted in the opposite direction. * If the EEPROM chip is faulty.
  • J
    jared69Sep 9, 2025
    What to do if the outdoor coil temperature sensor is in trouble in my Air-Con Air Conditioner?
    • A
      Andrew RhodesSep 9, 2025
      If the Air-Con Air Conditioner displays that the outdoor coil temperature sensor is in trouble, check the following: * Ensure the outdoor coil sensor is securely connected. * The outdoor coil temperature sensor might be faulty. * The outdoor control board might be faulty.
