ITEM# QTY PART # DESCRIPTION
1A 1 51001 7.5' SS PLOW BLADE
1B 1 51003 8.0' SS PLOW BLADE
1C 1 51005 8.5' SS PLOW BLADE
1D 1 51000 7.5' C PLOW BLADE
1E 1 51002 8.0' C PLOW BLADE
1F 1 51004 8.5' C PLOW BLADE
2 1 SET 10025 PLOW GUIDE ASSY W/ FASTENERS
3 8 01076 1/2" X 1 3/4" GR. 8 CARRIAGE BOLT
4 8 01487 1/2" TOPLOCK NUT
5A 1 51006 7.5' CUTTING EDGE
5B 1 51007 8.0' CUTTING EDGE
5C 1 51008 8.5' CUTTING EDGE
ITEM QTY PART# DESCRIPTION
6 2 51014 PLOW (SKID) SHOE ASSY
6A 2 01484 7/16" LYNCH PIN
6B 52 01471 1 1/16" ID X 1 3/4" OD FLAT WASHER
6C 2 51013 PLOW SHOE
7 1 24000 LABEL, SERIAL TAG
8 2 24090 LABEL, DANGER/WARNING
9 1 24095 LABEL, ATTACH/DETACH
10 1 24092 LABEL, AIR FLO
11 1 24094 LABEL, QUICKSILVER
12 1 24091 LABEL, LARGE AIR-FLO
A– BLADE SERVICE PARTS
manual-final.qxd 11/17/2006 12:45 PM Page 19
