Vehicle Side Wiring Harness - RELAYS
PLUGGING CHART FOR RELAYS
RELAY # 1 RELAY # 2 RELAY # 3
HIGH LOW GROUND
PIN# COLOR AWG PIN # COLOR AWG PIN # COLOR AWG
85 GREEN/YELLOW 18 85 GREEN/YELLOW 18 85 GREEN/YELLOW 18
86 WHITE/BLACK 18 86 WHITE/BLACK 18 86 WHITE/BLACK 18
30 YELLOW 16 30 GREEN 16 30 WHITE/RED 16
87 YELLOW/BLACK 16 87 GREEN/BLACK 16 87 WHITE 16
87a YELLOW/RED 16 87a GREEN/RED 16 87a N/A 18
manual-final.qxd 11/17/2006 12:45 PM Page 34
