B- QUADRANT SERVICE PARTS
ITEM# QTY PART # DESCRIPTION
1 4 01442 5/8" EYE BOLT ASSY
2 4 10016 TRIP SPRING
3 1 37052 SHOCK
4 1 51012 QUADRANT
5 3 01478 5/8" X 3" HEX BOLT GR. 8
6 3 01479 5/8" TOPLOCK NUT
7 2 01476 3/4" X 3 1/4" HEX BOLT GR. 8
8 1 01477 3/4" JAM NUT
9 1 01475 3/4" TOP LOCK NUT
QTY PART # DESCRIPTION
1 1 15064 BASE ASSEMBLY (18249)
2 1 15056 MOTOR DC, 12V - 4.5"
3 1 15057 CARTRIDGE 4-W/2-P
4 1 15058 CARTRIDGE 2W/2P, NC
5 4 15065 CAP SCREW SS 1/4"-20 X 2 3/4"
6 1 15059 SUCTION FILTER
7 1 15060 PUMP KIT
8 2 15066 TUBE, RTN 1/8" NPT
9 1 15067 TUBE, SUCTION 3/8" NPT
10 1 15061 RESV, 6 DIA X 5.5
11 1 15062 RESV, BREATHER - 3/8 NPT
12 1 15063 CARTRIDGE, 3W/2P
13 3 15055 COIL 10VDC, 2 PIN
14 1 15068 PLUG, FLUSH 3/8" NPT
F– NON RETAIL SERVICE PARTS (Not Shown)
manual-final.qxd 11/17/2006 12:45 PM Page 21
