C– A-FRAME SERVICE PARTS
ITEM# QTY PART # DESCRIPTION
1 1 51001 A-FRAME
2 2 01426 CHAIN - 30 LINKS
3 2 01010 3/8" U-BOLT
4 2 01018 3/8" FLAT WASHER
5 2 01016 3/8" LOCK WASHER
6 2 01270 3/8" NUT
7 1 01480 3/4" X 4" FLANGE BOLT GR.8
8 1 01475 3/4" TOPLOCK NUT
9 2 01011 3/4" X 3 1/2" HEX BOLT GR.8
10 2 01475 3/4" TOPLOCK NUT
11 2 37051 ANGLE CYLINDER
12 2 01189 5/32" X 3 1/2" COTTER PIN
13 2 01036 3/4" FLAT WASHER
14 2 01482 3/4" X 3 1/2" CLEVIS PIN
15 2 01472 5/16" X 1 1/2" LYNCH PIN
ITEM# QTY PART# DESCRIPTION
16 1 51031 S/S JACK ADJ. HANDLE
17 1 51032 S/S JACK HANDLE
18 1 09035 7/16" X 3 1/4" SILVER HANDLE COVER
19 1 51025 SCREW JACK FOOT
20 1 01508 3/4" INTERNAL RETAINING RING
21 1 10028 JACK RELEASE SPRING
22 1 51033 S/S JACK LOCK PIN
23 1 09038 7/16" X 2" SILVER HANDLE COVER
24 1 51026 LEFT HAND SCREW JACK MOUNT
25 1 51027 RIGHT HAND SCREW JACK MOUNT
26 1 51028 SCREW JACK EXTENTION TUBE
(NOT SHOWN)
27 1 01029 3/8" X 2" HEX BOLT GR. 8 - TUBE
EXTENSION (NOT SHOWN)
28 1 01486 3/8" X 2 3/4" HEX BOLT GR. 8 -
JACK FOOT
29 2 01034 3/8" LOCK NUT
