D– LOWER LIFT FRAME SERVICE PARTS
ITEM# QTY PART # DESCRIPTION
1 1 09037 RED VINYL GRIP
2 1 01430 DETENTION PIN W/ LANYARD
3 1 51023 LOCK HANDLE CATCH
4 1 51022 CAM BLOCK W/ CROSS SHAFT
(ASSEMBLED)
5 2 01428 7/9"-9 X 4 3/4" HEX BOLT GR. 8
6 2 01491 7/8" FLAT WASHER
7 2 01492 7/8" CENTERLOCK NUT
8 1 51021 LEFT HAND CAM ASSIST HANDLE
9 4 01019 5/16" X 2" ROLL PIN - SS
10 4 51015 TRUCK HITCH ROLLERS - SS
11 1 51020 RIGHT HAND CAM ASSIST HANDLE
12 2 09036 SILVER HANDLE COVER
ITEM# QTY PART# DESCRIPTION
13 1 01500 3/8" X 3/4" HEX BOLT GR. 8
14 1 01047 3/8" LOCK WASHER
15 1 01420 3/8" FLAT WASHER
16 1 01049 1/2" FLAT WASHER
17 1 01188 1/8" X 1" COTTER PIN
18 1 01420 3/8" FLAT WASHER
19 1 01188 1/8" X 1" COTTER PIN
20 4 01420 3/8" FLAT WASHER
21 1 01496 3/4" X 3" CLEVIS PIN
22 1 01189 5/32" X 1 1/2" COTTER PIN
23 4 01012 5/8" X 2" HEX BOLT GR.8
24 4 01479 5/8" TOPLOCK NUT
