3
TABLE OF CONTENTS
PAGE
HOW AIRBORNE CONTAMINATION IS REMOVED 3
DIMENSIONS 4
SPECIFICATIONS 6
PLANNING THE INSTALLATION 7
ASSEMBLY & INSTALLATION 10
CHECKOUT 16
MAINTENANCE 18
TROUBLE SHOOTING 21
PARTS IMAGES & PART NUMBERS 24
WARRANTY 27
HOW AIRBORNE CONTAMINATION IS REMOVED
A process called “Electrostatic Precipitation” traps airborne contaminants. The fan draws particulate
laden air successively through the prefilter, the cell ionizing section and the cell collector section. The
ionizing section imparts an electrical charge to the individual particles that are then drawn by electrostatic
forces to the oppositely charged collector plates. Cleaned air is then discharged back into the room.
The electronic cells must be washed periodically to maintain efficient performance.
