COMMISSIONING REPORT
HCV & HCVR Evaporative Cooling & Gas Heating
Page 23 of 26
COMMISSIONIN G REPORT
AIRA COMMISSIONING TEST HCV
Project Name
Project Number
Tag No.
Model No.
Serial No.
Attendees
1
2
3
4
Fan Test
Y/N
Comments
Is system operating or is this initial start?
Is the overall installation appears correct to gas
codes & manufactures specifications?
Is there any drag when fan is rotated?
Fan has correct rotation
Drive belt tension correct
Is there any unusual vibration? (Check throughout
fan range if variable speed)
Is there any unusual noise?
Is there any bearing noise ?
Is there any motor over-heating?
Check dampers open and close smoothly
Do the control dampers function as units
specifications?
Belt tension checked after operations
Design fan RPM:
Measured RPM:
Design amp Draw
L1
L2
L3
Measured
Amp Draw
L1
L2
L3
Motor
Contactor overloads set at
Low
High
Controls Test
Y/N
Comments
Main control switch plate wired correctly
Check thermostat wired correctly
Auto fan switch set at 40 c / 60 c (Honeywell L4064)
Campini 60c
High limit switches set at 100 c (Honeywell L4064)
Campini 85c Fixed no adjustment.
