AIREDALE LogiCool LCC20 - Electrical Data

Chillers
LOGICOOL™
Chillers
29
Technical Manual : 6521355 V1.14.0 11/2016
General Specification
ELECTRICAL DATA
LCC20
LCC40
Unit Data
Nominal Run Amps
(1)
A
14
28
Maximum Start Amps
(2)
A
103
117
Permanent Supply
VAC
230 V 1 PH 50 Hz
Mains Supply
VAC
400 V 3 PH 50 Hz
Rec Permanent Fuse Size
A
16
16
Rec Mains Fuse Size
A
25
40
Max Permanent Incoming Cable Size
mm²
4 mm² terminals
Max Mains Incoming Cable Size
mm²
35 (Direct to Isolator)
Control Circuit
VAC
24V/230VAC
Evaporator
Pad Heater Rating
W
25
25
External Trace Heating
Available (fitted by others)
W
500
500
AC Condenser Fan - Per Fan
Quantity
1
1
Motor Size
kW
0.98
1.80
Full Load Amps
A
1.75
3.80
Locked Rotor Amps
A
6.20
11.00
Compressor - Per Compressor
Quantity
1
1 + 1
Motor Size
kW
6.8
6.8 / 6 4
Nominal Run Amps
(1)
A
12.1
12.1 / 11.7
Start Amps
(2)
A
101
101 / 101
Type Of Start
Direct on line
OPTIONAL EXTRAS
Compressor Oil Heater Rating
W
70
70 / 70
Electronic Soft-start
Nominal Run Amps
(1)
A
14
28
Maximum Start Amps
A
63
77
Recommended Mains Fuse
A
25
40
EC Condenser Fan - Per Fan
Quantity
1
1
Full Load Amps
A
3.10
4.10
Motor Size
kW
1.85
2.60
Water Pump
Single Head or Run/Standby - Standard
Unit Nominal Run Amps
(1)
A
15
30
Recommended Mains Fuse
A
25
40
Motor Size
kW
0.37
0.50
Full Load Amps
A
1.40
1.90
Single Head or Run/Standby - Larger
Unit Nominal Run Amps
(1)
A
16
31
Recommended Mains Fuse
A
25
40
Motor Size
kW
0.75
0.90
Full Load Amps
A
2.30
3.00
(1)
To ARI standard conditions ARI 540 (7.2°C evaporating; 54.4°C condensing).
(2)
Starting amps refers to the direct on line connections.
