AIRFIX A20005 User Manual

Assembly sequence 49
Assembly sequence 50
Assembly sequence 51
Secure the aerofoil halves together
using four screws
Assemble the large front fan
engine blades
Push the engine spindle into
assembled large fan blades
23
Assembly sequence 10
Assembly sequence 11
Assembly sequence 12
Twist the exposed cable ends
together
Cut a length of shrink sleeve and
slide over the cables
Fold the exposed cable ends to
secure them together and to enable
the shrink sleeve to pass over the
top of the exposed part of the
cables
jet engine
A
A
A
BLACK
RED
10

AIRFIX A20005 Specifications

General

Brand	AIRFIX
Model	A20005
Category	Engine
Language	English
