Installation and Operation Instructions
3.3 Wall or ceiling installation
3.4 Cable connections
1. Pull cable through grommet, don’t cut open!
2. Cut cable at least to length 180 mm and remove cable jacket at least 100 mm in length.
3. Connect fan according to wiring diagram (see page 5).
4. Run cable in the conduit.
fig.6 fig.7
1. Press cover of control board (2) on casing and
fasten with screws.
2. Snap in fascia. (1)
1
2
3
- Length of single conductor 100 mm
- Length of stripped insulation 7 mm
- Strip plastic-sheathed cable flush with conduit.
100 mm
fig.5fig.4
With installation of the device, the
guide vane (5) must be mounted
vertically (as shown). Snaps into
place every 90° rotation.
If installed in the ceiling the pre-cut drillings (2)
must be punched through because of possible
condensate formation.
1
Break out entry
knockout for cable.
?
?
2
2
Guide vane (5)
removable
fig.9fig.8
Standard installation
Guide vane with
back draught
shutter
Mount guide
vane with
back draught
shutter at the
end of the
duct or just
omit it.
Fan
Duct channel
90° bend
Assembly at cramped
place conditions
Back
draught
shutter (6)
removable
5
Affix the
rubber foam
vertical
Snap in fascia
7 mm
