DP-airless Page 7 of 22
7
Motor Make the power for machine.
8
Oil cover Prevent the oil leaked out. (please change the 46#
hydraulic oil inside after 300 hours using)
9
On-off switch Turns sprayer ON and OFF.
10
** Outlet valve The valve control the fluid going out of the pump
11
Pressure regulator Increases (clockwise) and decreases (counter-clockwise)
fluid pressure in pump, hose, and spray gun.
12
Hose Connector Connect the high pressure hose with airless spray gun.
13
** Inlet valve The valve control the fluid sucking into the pump
14
Belt To reduce the power from Motor, and supply the right power
to the machine.
15(1)
**Diaphragm Moved by the piston inside, and pump out the fluid.
15
High pressure hose Transports high-pressure fluid from pump to spray gun.
16
** Tip guard / Safety guard Reduces risk of fluid injection injury.
17
** Spray gun tip Atomizes fluid being sprayed, forms spray pattern and
controls fluid flow according to hole size.
Reverse unclogs plugged tips without disassembly.
18
Gun trigger safety lever / lock Prevents accidental triggering of spray gun.
(please lock the spray gun when not using/repair/clean etc)
19
Airless spray gun Dispenses fluid.
20
Gun fluid inlet fitting Threaded connection for paint hose.
(the parts marked with ** are easily worn parts.)
