Airstream Basecamp 2007 - Converter

G
G - 12
ELECTRICAL SYSTEM
Circuit 3, 15 amp, GFI Breaker
Outside Receptacle
Curbside Lounge Area Receptacle
Roadside Lounge Area Receptacle
Galley Area Receptacle
110 Volt Wiring Diagram
30 amp Man Circuit
Circuit 1, 15 amp, HACR Breaker
Air Conditioner Receptacle
Circuit 2, 15 amp, HACR Breaker
Converter
M 1
2
3
Power Cord
Air Conditioner
Galley
Conv
erter
Outside Receptacle
Cu
rbside Lounge
Roadside Lounge
