Installation
3.7.7 Set the Unit IP Addresses
The IP address of each unit needs to be set prior to integration into the control network.
1. Connect a PGD to the control module inside the unit using the preinstalled connector.
2. Hold the Esc button until the main screen is displayed.
3. Hold Alarm and Enter for 3 seconds to enter the unit configuration menu.
4. Press Down until the cursor is over “Settings” and press Enter.
5. Press Down until the cursor is over “TCP/IPv4 Configuration” and press Enter.
6. Press Enter until the cursor is over the relevant fields of the IP address and Mask. Use the Up or Down
buttons to change them to the desired values.
IP Settings:
•
If the previous section on changing IP for the controller was skipped, set the IP Address to 192.168.11.X
where X is the unit number. For example, for Unit #3, set the IP Address to 192.168.11.3
•
If the customer provides IP settings for each HVAC, change the values on the units accordingly.
•
If the controller IP was changed for remote monitoring, set the IP Address to Y.Z.11.X where Y and Z
are the same as that of the controller and X is the unit number. For example, if the controller IP is set to
192.168.20.45, set Unit #1 to 192.168.11.1 and Unit #2 to 192.168.11.2.
•
Mask: Always use 255.255.0.0
•
Leave other fields blank.
7. Press Enter until the cursor is over “Update Config” and press Up to change “No” to “Yes”.
8. Press Enter.
9. Repeat steps 1-8 for all units to be installed.
3.7.8 Verify the Unit Model Number
1. On the main controller hold the Esc button until the main screen is displayed.
2. From the Main Screen, press Prg and enter the password (0004).
3. Press Down until the cursor is over “HVAC Config” and press Enter. The cursor should be over “Unit
Model”. Press Enter.
4. Verify that the displayed model number is consistent with the nameplate. Use the Up and Down buttons
to change the model until it is correct. Press Enter to confirm.
3.7.9 Optional: Set the Unit Serial Number
1. On the main controller hold the Esc button until the main screen is displayed.
2. From the Main Screen, press Prg and enter the password (0004).
3. Press Down until the cursor is over “HVAC Config” and press Enter. The cursor should be over “Unit
Model”. Press Enter.
4. Press Down until the cursor is over “Serial Number”, the press Enter.
5. Use the Up and Down buttons to change each digit of the serial number and press Enter to move to the
next number.
