Installation
47
•
The Smoke/Fire Alarm is connected to 41 and 5 on the controller terminal block. If the smoke/fire detector
does not have a test button, remove one of the wires from terminals 41 and 5; the system should shut
down. It may take the compressor 30 seconds to stop.
3. Verify HVAC Alarms
•
HVAC1: Turn off the HVAC 1 prime power breaker at panel or unit. Verify NO terminal 44 and 45 is
Closed.
•
HVAC2: Turn off the HVAC 2 prime power breaker at panel or unit. Verify NO terminal 46 and 47 is
Closed.
•
HVAC3: Turn off the HVAC 3 prime power breaker at panel or unit. Verify NO terminal 47 and 48 is
Closed.
3.7.19 Clearing Alarm History
At significant points such as during preventative maintenance and after commissioning, it may be desired to
clear the alarm history.
Warning. Alarm history is collected because it can be very helpful in identifying
a problem with the system. The alarm history should never be arbitrarily cleared
by an operator. Only AAST should clear the alarm history after all the alarms
stored in history have been recorded.
To clear the alarm history, perform the following steps:
1. Hold the Esc button until the main screen is displayed.
2. Press Prg and enter the password (0004). Press Enter.
3. Press Down until the cursor is over “System” and press Enter.
4. Press Down until the cursor is over “Initialization” and press Enter.
5. Press Down until the cursor is over “Delete Alarm Logs” and press Enter.
6. Press Up or Down until the “no” becomes “yes” and press Enter.
3.7.20 Enable SNMP (Optional)
SNMP is available on the ASMUC as an optional extra. To enable it, perform the following steps:
1. Hold the Esc button until the main screen is displayed.
2. Press Prg and enter the password (0004). Press Enter.
3. Press Down until the cursor is over “System” and press Enter.
4. Press Down until the cursor is over “Serial Ports” and press Enter.
5. Press Down until “SNMP Recipients Config” is displayed across the top.
6. Press Enter until the cursor is next to “SNMP” and use the Up or Down buttons to change “No” to “YES”.
7. Press Enter to confirm.
8. Press Enter until the cursor is over the IP address fields.
9. Use the Up and Down buttons to change the value of each part of the IP address. When finished, press
Enter to move to the next part of the IP address.
