Airwell DLS 18 - PRODUCT DATA SHEET

2-1
PRODUCT DATA SHEET
SM DLSRPM 1-A.4 GB
(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN14511.
(2) Airflow in ducted units; at nominal external static pressure.
(3) Sound power in ducted units is measured at air discharge.
(4) Sound pressure level measured at 1 meter distance from unit.
2. PRODUCT DATA SHEET
2.1 DLS 18 / GC 18 1PH R410A
Model Indoor Unit DLS 18
Model Outdoor Unit GC 18 R410A
Installation Method
DUCTED
Characteristics Units Cooling Heating
Capacity
(1)
Btu/hr 19100 18000
kW 5.6 5.3
Power Input
(1)
kW 1.8 1.7
COP
(1)
W/W 3.05 3.12
Energy Efficiency Class B D
Power Supply V/Ph/Hz 230/50/1
Rated Current A 8.2 7.5
Starting Current A 43
Circuit Breaker Rating A 20
INDOOR
Fan Type & Quantity CENTRIFUGAL X1
Fan Speed H/M/L RPM 630 530 425
Airflow
(2)
H/M/L m
3
/hr 1150 875 730
External Static Pressure Min-Max Pa 25-60
Sound Power Level
(3)
H/M/L dB (A) 55 53 50
Sound Pressure Level
(4)
H/M/L dB (A) 45 42 40
Moisture Removal L/hr 2.0
Condensate Drain Tube I.D. mm 19
Dimensions W/H/D mm 770 260 690
Weight kg 29
Package Dimensions W/H/D mm 949 315 851
Packaged Weight kg 31
Units per Pallet Units 6
Stacking Height Units 6
OUTDOOR
Refrigerant Control Capillary
Compressor Type, Model Rotary
Fan Type & Quantity Axial & 1
Fan Speeds H/L RPM 815
Airflow H/L m
3
/hr 2480
Sound Power Level H/L dB (A) 68
Sound Pressure Level
(4)
H/L dB (A) 58
Dimensions W/H/D mm 846 690 302
Weight kg 56
Package Dimensions W/H/D mm 990 770 430
Packaged Weight kg 61
Units per Pallet Units 9
Stacking Height Units 3
Refrigerant Type R 410A
Refrigerant Chargeless Distance kg/m 1.75/10.0
Additional Charge Per 1 Meter g/m 25
Connections
Between Units
Liquid Line In 1/4''
Suction Line In 1/2''
Max. Tubing Length m 25
Max. Height Difference m 15
Operation Control Type LCD Remote Control
Heating Elements kW
Others
