11-13
CONTROL SYSTEM
SM PNXADCI 1-A.1 GB
11.1 . Indoor Unit Controller21
11.12 Jumper Setting
0 = Open Jumper (disconnect jumper).
1 = Close Jumper (connect jumper).
Self test Jumper – J1
OPERATION
J1
SELF-TEST
1
NORMAL
0
Compensation Jumper – J2
Model J2 (Default) Compensation
Wall Mounted 0 Activated
Floor/Ceiling 1 Deactivated
Ducted/cassette 1 Activated
Family selection Jumper – J3, J4 and J5
Family J5 J4 J3
Reserved
Reserved
Reserved
Wall Mounted (WNG/FLO)
Floor/Ceiling (PXD)
Reserved
Ducted (LS)
Cassette (K)
00 0
00 1
01 0
01 1
10 0
10 1
11 0
11 1
IDU Model
Jumper Setting
J8 J7 J6 J5 J4 J3
FLO 9 000011
FLO 12 010011
FLO 18 001000
FLO 28 001001
SX 9 000100
SX 12 010100
SX 18 100100
K 9 000111
K 12 010111
K 18 100111
LS12 010110
)RUZDOOPRXQWHGXQLWV-XPSHUVMMFDQEHFRQ¿JXUHGE\VHUYLFH All other jumpers on
the above table are factory default (cannot be changed by service).
)RUXQLWW\SHVDV&DVVHWWHVÀRRUFHLOLQJDQGGXFWHGMXPSHUVDUHVHWE\DPRGHOSOXJ
