PRODUCT DATA SHEET
Revision 0
Model Indoor Unit FLO 14 N
Model Outdoor Unit GC14 N (ONG-14)
Installation Method of Pipe Flared
Characteristics Units Cooling Only Cooling Heating
Capacity
(1)
Btu/hr 13650 13650 15290
kW 4.0 4.0 4.48
Power input
(1)
kW 1.33 1.33 1.395
EER (Cooling) or COP(Heating)
(1)
W/W 3.01 3.01 3.21
Energy efficiency class
B
BC
Power supply V/Ph/Hz 220-240V/Single/50Hz
Rated current A 6.1 6.1 6.5
Starting current A 30
Circuit breaker rating A 15
INDOOR
Fan type & quantity Crossflow x 1
Fan speeds H/M/L RPM 1280/1080/930
Air flow
(2)
H/M/L m3/hr 660/550/475
External static pressure Min-Max Pa 0
Sound power level
(3)
H/M/L dB(A) 56/51/46
Sound pressure level
(4)
H/M/L dB(A) 46/41/36
Moisture removal l/hr 1.5
Condenstate drain tube I.D mm 16
Dimensions WxHxD mm 810x190x285
Weight kg 11.5
Package dimensions WxHxD mm 885x360x285
Packaged weight kg 14
Units per pallet units 32
Stacking height units 8 levels
OUTDOOR
Refrigerant control Capillary tube
Compressor type,model Rotary,RN165VHSMT
Fan type & quantity Propeller(direct) x 1
Fan speeds H/L RPM 920
Air flow H/L m3/hr 2160
Sound power level H/L dB(A) 63 64
Sound pressure level
(3)
H/L dB(A) 53 54
Dimensions WxHxD mm 795x290x610
Weight kg 41.5 42.2
Package dimensions WxHxD mm 945x395x655
Packaged weight kg 45.5 46.5
Units per pallet Units 9
Stacking height units 3 levels
Refrigerant type R410A
Refrigerant chargless distance kg/m 1.34kg/7.5m
Additional charge per 1 meter g/m 20
Connections between
units
Liquid line In.(mm) 1/4”(6.35)
Suction line In.(mm) 1/2”(12.7)
Max.tubing length m. Max.15
Max.height
difference
m. Max.7
Operation control type Remote control
Heating elements (Option) kW 0.3
Others
(1)
Rating conditions in accordance with ISO 5151, ISO 13253 (for ducted units) and EN 14511.
(2)
Airflow in ducted units; at nominal external static pressure.
(3)
Sound power in ducted units is measured at air discharge.
(4)
Sound pressure level measured at 1 meter distance from unit.
