Airwell YCV Series Service Manual

4
Model AWAU-YCV080-H11 AWAU-YCV125-H11
Outdoor coil
Number of rows 2 2
Tube pitch (a)×row pitch (b) mm 21*18.186 21*18.186
Fin spacing mm 1.4 1.40
Fin type (code) Corrugated Corrugated
Fin coating type Optional Hydrophilic aluminum Hydrophilic aluminum
Salt spray test duration Hour 500 500
Tube outside dia. and type
Internal thread copper tube
Internal thread copper
tube
mm Ф7 Ф7
Coil length×height mm 955×792 970×1197
Number of circuits 6 7
Cabinet coating
Coating type Powder Coating Powder Coating
Salt spray test duration Hour 500 500
Sheet metal material Hot zinc plate Hot zinc plate
Sheet metal thickness mm 0.8 0.8
Control panel enclosure IP class Standard IP24 IP24
Outdoor air flow m
3
/h 3500 6500
Outdoor sound level (sound pressure level ) dB (A) 54 58
Outdoor sound level (sound power level ) dB (A) 65 69
Outdoor unit
Dimension (W*H*D) mm 960/340/830 960/340/1250
Packing (W*H*D) mm 1095×410×945 1095×410×1400
Net weight kg 70 99
Gross weight kg 76 107
Refrigerant
Type R410A R410A
Charged volume kg 2.4 3.8
Throttle type EXV EXV
Design pressure MPa 4.15 4.15
Refrigerant piping
Liquid pipe mm 9.52 9.52
Gas pipe mm 15.88 19.05
Total pipe length m 100 150
Max. pipe length m 50 70
Max. Di󰀨. indoor/outdoor unit m
30(Outdoor higher than indoor)
20(Indoor higher than outdoor)
Max. Di󰀨. indoor/indoor unit m 10 10
Connectable indoor unit ratio % 50%~130% 50%~130%
Maximum indoor units Piece 5 8
Connection wiring
Power wiring mm
2
6 16
Signal wiring mm
2
Shield wire:(0.75-2)*2 Shield wire:(0.75-2)*2
Operation range °C
Cooling: 10~48
Heating: -15~21
Cooling: -5~48
Heating: -15~21
Nominal condition:
Indoor temperature (cooling): 27 DB(°C)/19 WB(°C), indoor temperature (heating): 20 DB(°C)/14.5 WB(°C).
Outdoor temperature (cooling): 35 DB(°C)/24 WB(°C), outdoor temperature (heating): 7 DB(°C)/6 WB(°C).
The data is measured with 7.5m equivalent pipe and 0m height di󰀨erence.
The noise level will be measured in the third octave band limited values in the semi-anechoic chamber, using a
real time analyser calibrated sound intensity meter. It is a sound pressure noise level.
