6
Model AWAU-YCV150-H11
Outdoor coil
Number of rows 2
Tube pitch (a)×row pitch (b) mm 21*18.186
Fin spacing mm 1.40
Fin type (code) Corrugated
Fin coating type Optional Hydrophilic aluminum
Salt spray test duration Hour 500
Tube outside dia. and type
Internal thread copper tube
mm Ф7
Coil length×height mm 970×1197
Number of circuits 7
Cabinet coating
Coating type Powder Coating
Salt spray test duration Hour 500
Sheet metal material Hot zinc plate
Sheet metal thickness mm 0.8
Control panel enclosure IP class Standard IP24
Outdoor air flow m
3
/h 6500
Outdoor sound level (sound pressure level ) dB (A) 58
Outdoor sound level (sound power level ) dB (A) 69
Outdoor unit
Dimension (W*H*D) mm 960/340/1250
Packing (W*H*D) mm 1095×410×1400
Net weight kg 99
Gross weight kg 107
Refrigerant
Type R410A
Charged volume kg 3.8
Throttle type EXV
Design pressure MPa 4.15
Refrigerant piping
Liquid pipe mm 9.52
Gas pipe mm 19.05
Total pipe length m 150
Max. pipe length m 70
Max. Di. indoor/outdoor unit m
Max. Di. indoor/indoor unit m 10
Connectable indoor unit ratio % 50%~130%
Maximum indoor units Piece 8
Connection wiring
Power wiring mm
2
16
Signal wiring mm
2
Shield wire:(0.75-2)*2
Operation range °C
Cooling: -5~48
Heating: -15~21
Nominal condition:
Indoor temperature (cooling): 27 DB(°C)/19 WB(°C), indoor temperature (heating): 20 DB(°C)/14.5 WB(°C).
Outdoor temperature (cooling): 35 DB(°C)/24 WB(°C), outdoor temperature (heating): 7 DB(°C)/6 WB(°C).
The data is measured with 7.5m equivalent pipe and 0m height dierence.
The noise level will be measured in the third octave band limited values in the semi-anechoic chamber, using a
real time analyser calibrated sound intensity meter. It is a sound pressure noise level.
