Revised 02.19.10 www.AIS-INC.com 17
AIS DiVi Installation Instructions (P-DVINSTRUCT01)
Hold metal divide over glide
housings as shown and slide
clamp over end to trap divider
and glide housing.
Using screws provided, “close”
clamp to grip glide housing as
shown. Make sure metal
barrier is sitting flush with
underside of powerway.
Connecting bridges for 2-ways
and 3-ways of all angles, as
well a 4-way 90 degrees, are
used to make the metal barrier
continuous throughout the
entire system.
