Revised 02.19.10 www.AIS-INC.com 3
AIS DiVi Installation Instructions (P-DVINSTRUCT01)
Panels interlocked prior to
hinge installation.
Push panels together at the
top. Level panels such that
side rails remain parallel and
flush. This will make hinge
installation easier. Note hinge
channels formed when panels
are aligned.
Slide 20 7/8 inch long hinge
down into hinge channels.
To Next Page
