Top Glass Insert Tiles Cont.
Tap gently
IMPORTANT INSTRUCTIONS:
• Install tile frames by first inserting top
edge of tile under the top tile retainer lip.
• While holding the tile frame up, rotate
bottom of the tile frame down and gently
tap bottom of the tile frame into the
bottom tile retainer.
Foam blocks at
top of the tile.
Glass Tile Front Frame
Glass Tile Back Frame
IN / DOWN
UP
IN / DOWN
UP
