Aiwa AV-D77 - Specifications

– 2 –
FM tuner section
Tuning range 87.5 MHz to 108 MHz
Usable sensitivity (IHF) 13.2 dBf
Antenna terminals 75 ohms (unbalanced)
AM tuner section
Tuning range 530 kHz to 1710 kHz (10 kHz step)
531 kHz to 1602 kHz (9 kHz step)
Usable sensitivity 350 µV/m
Antenna Loop antenna
Amplifier section
Power output [Stereo Mode]
Front
Rated: 140 W + 140 W
(8 ohms, T.H.D. 1 %, 1 kHz)
Reference: 180 W + 180 W
(8 ohms, T.H.D. 10 %, 1 kHz)
[Dolby Digital Surround or Dolby
Pro Logic Mode]
Front
Rated: 95 W + 95 W
(8 ohms, T.H.D. 1 %, 1 kHz)
Reference: 120 W + 120 W
(8 ohms, T.H.D. 10 %, 1 kHz)
Rear (Surround)
Rated: 95 W + 95 W
(8 ohms, T.H.D. 1 %, 1 kHz)
Reference: 120 W + 120 W
(8 ohms, T.H.D. 10 %, 1 kHz)
Center
Rated: 95 W
(8 ohms, T.H.D. 1 %, 1 kHz)
Reference: 120 W
(8 ohms, T.H.D. 10 %, 1 kHz)
Total harmonic distortion 0.08 % (80 W, 1 kHz, 8 ohms, Front)
Inputs AUDIO IN
PHONO: 2.5 mV,
adjustable (47 kohms)
CD, VIDEO 1/DVD/MD, VIDEO 2/
LD/TV, VIDEO 3: 300 mV,
adjustable (47 kohms)
TAPE MONITOR: 350 mV,
adjustable (47 kohms)
AUX: 250 mV,
adjustable (47 kohms)
DIGITAL IN
COAXIAL (VIDEO 2) :
OPTICAL (VIDEO 1) :
OPTICAL (VIDEO 3) :
accept linear PCM signals
and bit stream of Dolby Digital
Surround (32 kHz, 44.1 kHz and
48 kHz and 96 kHz)
VIDEO IN : 1 Vp-p (75 ohms)
SPECIFICATIONS
Outputs AUDIO OUT (REC OUT): 300 mV
(1 kohm)
VIDEO OUT (MONITOR): 1 Vp-p
(75 ohms)
SUB WOOFER: 5.0 V
FRONT SPEAKERS IMP: 8 / 4 ohms
selectable (front speakers A and B ):
with the SPEAKER IMPEDANCE
SELECTOR set to 4 ohms, accepts
speakers of 4 ohms.
with the SPEAKER IMPEDANCE
SELECTOR set to 8 ohms, accepts
speakers of 8 ohms or more
SURROUND SPEAKERS IMP: 8 ohms
(surround speakers): accepts
speakers of 8 ohms or more
CENTER SPEAKER IMP: 8 / 4 ohms
selectable with the SPEAKER
IMPEDANCE SELECTOR set to 4
ohms, accepts speakers of 4 ohms.
with the SPEAKER IMPEDANCE
SELECTOR set to 8 ohms, accepts
speakers of 8 ohms or more
PHONES (stereo jack): accepts
headphones of 32 ohms or more
Muting -20 dB
General
Power requirements 120/220-230/240 V AC, switchable
50/60 Hz
Power consumption 290 W
Power consumption in ECO OFF: 48 W
standby mode ECO ON: 1.5 W
Dimensions 430 x 155 x 402 mm
(W x H x D)
Weight 12.4 kg
• Design and specifications are subject to change without notice.
• Manufactured under license from Dolby Laboratories Licensing
Corporation.
“DOLBY”, the double-D symbol and "PRO LOGIC" are
trademarks of Dolby Laboratories Licensing Corporation.
• The word "BBE"and the "BBE symbol" are trademarks of BBE
Sound, Inc.
Under license from BBE Sound,Inc.
