Aiwa CSD-EX150 User Manual

6
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
ELECTRICAL MAIN PARTS LIST
IC
87-A20-955-010 IC,LA1828
87-070-416-010 IC,NJU7201 L55
87-A21-111-040 C-IC,M62495FP
87-A20-946-040 C-IC,MM1434XF
87-A21-193-010 IC,TA8227P
87-A21-145-040 C-IC,BA4560F-E2
87-A20-446-010 C-IC,LA9241ML
87-A20-459-010 C-IC,LC78622ED
87-A20-856-010 IC,BA6898S
8Z-CDB-651-010 C-IC,LC865516A-5L84
TRANSISTOR
89-319-233-080 TR,2SC1923 (0.1W)
87-026-572-080 TR,DTA114TS
87-026-215-080 TR,DTC114YS
87-026-291-080 TR,DTC124XS
89-318-154-080 TR,2SC1815 (0.4W)
89-113-184-080 TR,2SA1318T
89-112-965-080 TR,2SA1296 (0.75W)
87-026-463-080 TR,2SA933S (0.3W)
89-320-011-080 TR,2SC2001 (15W)
89-318-155-080 TR,2SC1815 (0.4W)
87-026-462-080 TR,2SC1740 S(RS 0.3W)
89-110-155-080 TR,2SA1015(0.4W)
87-026-496-080 FET,2SJ103GR
89-328-786-080 TR,2SC2878B
87-026-217-080 TR,DTC124ES
87-026-235-080 CHIP-TR,DTC114EK
87-026-211-080 TR,DTA144EK
87-026-447-080 TR,2SC1740S R
DIODE
87-020-465-080 DIODE,1SS133 (110MA)
87-017-162-080 ZENER,HZS7C3L
87-017-148-080 ZENER,HZS6A1L
87-070-136-080 ZENER,MTZJ5.1B
87-027-399-080 ZENER,HZ7A3L (200MA)<U>
87-027-607-080 ZENER,HZ7B3L<HR,HC>
87-017-139-010 ZENER,HZS15-2
87-A40-466-080 ZENER,MTZJ2.7A
87-A40-465-090 DIODE,FR202
MAIN C.B
C1 87-010-314-080 C-CAP,S 22P-50V
C2 87-010-316-080 C-CAP,S 33P-50 CH
C3 87-010-314-080 C-CAP,S 22P-50V
C5 87-010-151-080 C-CAP,S 7P-50 CH
C6 87-010-378-080 CAP, ELECT 10-16V
C7 87-018-208-080 CAP 0.047-50F
C8 87-010-197-080 CAP, CHIP 0.01 DM
C9 87-010-154-080 CAP CHIP 10P
C10 87-010-197-080 CAP, CHIP 0.01 DM
C12 87-010-314-080 C-CAP,S 22P-50V
C13 87-010-148-080 CAP, CHIP S 75P SL
C14 87-010-400-080 CAP, ELECT 0.47-50V
C15 87-010-197-080 CAP, CHIP 0.01 DM
C16 87-010-178-080 CHIP CAP 1000P
C17 87-016-669-080 C-CAP,S 0.1-25 K B
C18 87-016-460-080 C-CAP,S 0.22-16 B
C19 87-010-544-080 CAP, ELECT 0.1-50V
C20 87-010-400-080 CAP, ELECT 0.47-50V
C21 87-010-403-080 CAP, ELECT 3.3-50V
C22 87-010-197-080 CAP, CHIP 0.01 DM
C24 87-010-197-080 CAP, CHIP 0.01 DM<HR,HC>
C24 87-010-188-080 CAP,CHIP 6800P<U>
C25 87-010-197-080 CAP, CHIP 0.01 DM<HR,HC>
C25 87-010-188-080 CAP,CHIP 6800P<U>
C26 87-016-460-080 C-CAP,S 0.22-16 B
C27 87-016-460-080 C-CAP,S 0.22-16 B
C28 87-010-194-080 CAP, CHIP 0.047
C29 87-010-194-080 CAP, CHIP 0.047
C30 87-010-248-080 CAP, ELECT 220-10V
C31 87-010-379-080 CAP, ELECT 22-16V
C32 87-010-197-080 CAP, CHIP 0.01 DM
C33 87-010-197-080 CAP, CHIP 0.01 DM
C34 87-010-197-080 CAP, CHIP 0.01 DM
C37 87-012-155-080 C-CAP 180P-50CH
C38 87-010-318-080 C-CAP,S 47P-50 CH
C91 87-010-197-080 CAP, CHIP 0.01 DM
C92 87-010-178-080 CHIP CAP 1000P
C97 87-018-134-080 CAPACITOR,TC-U 0.01-16<U>
C98 87-010-197-080 CAP, CHIP 0.01 DM<U>
C203 87-010-401-080 CAP, ELECT 1-50V
C204 87-010-221-080 CAP, ELECT 470-10V
C205 87-010-263-080 CAP, ELECT 100-10V
C206 87-010-248-080 CAP, ELECT 220-10V
C206 87-010-248-080 CAP, ELECT 220-10V
C210 87-010-198-080 CAP, CHIP 0.022
C211 87-010-260-080 CAP, ELECT 47-25V
C212 87-010-198-080 CAP, CHIP 0.022
C220 87-016-495-090 CAP,E 3300-25 SMG
C230 87-010-405-080 CAP, ELECT 10-50V
C231 87-010-404-080 CAP, ELECT 4.7-50V<HR,HC>
C232 87-010-263-080 CAP, ELECT 100-10V
C233 87-010-197-080 CAP, CHIP 0.01 DM
C234 87-010-263-080 CAP, ELECT 100-10V
C261 87-010-196-080 CHIP CAPACITOR,0.1-25
C262 87-010-384-080 CAP, ELECT 100-25V
C263 87-010-385-080 CAP, ELECT 220-25V
C264 87-010-196-080 CHIP CAPACITOR,0.1-25
C265 87-010-236-080 CAP,E 1000-10 SME
C301 87-010-405-080 CAP, ELECT 10-50V
C302 87-010-405-080 CAP, ELECT 10-50V
C303 87-010-405-080 CAP, ELECT 10-50V
C304 87-010-404-080 CAP, ELECT 4.7-50V
C305 87-010-213-080 C-CAP,S 0.015-50 B
C306 87-010-546-080 CAP, ELECT 0.33-50V
C307 87-010-544-080 CAP, ELECT 0.1-50V
C308 87-010-260-080 CAP, ELECT 47-25V
C309 87-010-263-080 CAP, ELECT 100-10V
C310 87-010-544-080 CAP, ELECT 0.1-50V
C311 87-010-546-080 CAP, ELECT 0.33-50V
C312 87-010-213-080 C-CAP,S 0.015-50 B
C313 87-010-404-080 CAP, ELECT 4.7-50V
C314 87-010-405-080 CAP, ELECT 10-50V
C315 87-010-405-080 CAP, ELECT 10-50V
C316 87-010-405-080 CAP, ELECT 10-50V
C317 87-010-401-080 CAP, ELECT 1-50V
C318 87-010-401-080 CAP, ELECT 1-50V
C319 87-010-197-080 CAP, CHIP 0.01 DM
C320 87-010-405-080 CAP, ELECT 10-50V
C321 87-010-260-080 CAP, ELECT 47-25V
C322 87-010-402-080 CAP, ELECT 2.2-50V
C325 87-010-400-080 CAP, ELECT 0.47-50V
C326 87-010-400-080 CAP, ELECT 0.47-50V
C329 87-010-401-080 CAP, ELECT 1-50V
C330 87-010-197-080 CAP, CHIP 0.01 DM
C331 87-010-197-080 CAP, CHIP 0.01 DM
C332 87-010-197-080 CAP, CHIP 0.01 DM
C333 87-010-197-080 CAP, CHIP 0.01 DM
C334 87-010-404-080 CAP, ELECT 4.7-50V
C335 87-010-401-080 CAP, ELECT 1-50V
C336 87-010-401-080 CAP, ELECT 1-50V
C337 87-010-178-080 CHIP CAP 1000P
C338 87-010-384-080 CAP, ELECT 100-25V
C339 87-010-404-080 CAP, ELECT 4.7-50V
