Aiwa CSD-FD79 Service Manual

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-10-
ELECTRICAL PARTS LIST - 5/12 (CSD-FD79/77) - 5 /10
CSD-FD77 CSD-FD79
CSTC USTC
MAIN O C 0471 87-A11-088-080 CAP,TC U 100P-50 J CH a b
MAIN O C 0473 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b
MAIN O C 0474 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b
MAIN O C 0475 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b
MAIN O C 0476 87-012-278-080 C-CAP,U 2200P-50 K B GRM a b
MAIN O CN 0101 87-049-919-010 CONN,3P V WHT EH a b
MAIN O CN 0203 87-049-469-010 CONN,4P V WHT EH a b
MAIN O CN 0302 87-099-832-010 CONN,8P V S2M-8W a b
MAIN O CN 0401 87-A60-424-010 CONN,16P V TOC-B a b
MAIN O CN 0402 87-A60-619-010 CONN,2P V 2MM JMT a b
MAIN O CN 0801 87-A60-054-010 CONN,14P V 9604S-14C a b
MAIN O CN 0802 87-A60-054-010 CONN,14P V 9604S-14C a b
MAIN O CNA0102 8C-CHE-659-010 CONN ASSY,7P MAIN-TU a b
MAIN O CNA0203 8C-CHE-666-010 CONN ASSY,4P MAIN-SPL/R a b
MAIN O CNA0302 8C-CHE-658-010 CONN ASSY,8P MAIN-TAPE a b
MAIN O CNA0401 8C-CHE-656-010 CONN ASSY,6P CD-CDMECHA a b
MAIN O CNA0402 8C-CHE-657-010 CONN ASSY,2P CD-DOORSW a b
MAIN S D 0106 87-070-345-080 DIODE,1N4148 a b
MAIN S D 0107 87-070-345-080 DIODE,1N4148 a b
MAIN S D 0108 87-020-465-080 DIODE,1SS133 a b
CSD-FD77 CSD-FD79
CSTC USTC
MAIN S D 0109 87-020-465-080 DIODE,1SS133 a b
MAIN S D 0110 87-017-162-080 ZENER,HZS7C3L a b
MAIN S D 0401 87-020-465-080 DIODE,1SS133 a b
MAIN S D 0403 87-A40-743-080 ZENER,UZ4.3BSA a b
MAIN S D 0404 87-A40-747-080 ZENER,UZ5.1BSB a b
MAIN O FFC0001 8C-CHE-652-010 FF-CABLE,14P 1.25 FR-MAIN1 a b
MAIN O FFC0002 8C-CHE-653-010 FF-CABLE,14P 1.25 FR-MAIN2 a b
MAIN O FFC0004 8C-CHE-654-010 FF-CABLE,16P 1.0 CD-PU a b
MAIN S IC 0202 87-A21-193-010 IC,TA8227P a b
MAIN S IC 0203 87-A22-236-040 C-IC,BD3881FV a b
MAIN S IC 0401 87-A22-242-030 C-IC,LC78646E a b
MAIN S IC 0402 87-A22-115-010 C-IC,MM1469PH a b
MAIN O J 0201 8C-NF8-680-010 JACK,CKX-3.5-25 ST W/O SW a b
MAIN X JR 0301 88-108-000-080 C-JUMPER,U a b
MAIN X JR 0302 88-108-000-080 C-JUMPER,U a b
MAIN X JR 0303 88-108-000-080 C-JUMPER,U a b
MAIN X JR 0308 88-108-000-080 C-JUMPER,U a b
MAIN X JR 0401 88-108-000-080 C-JUMPER,U a b
MAIN X JR 0403 88-108-000-080 C-JUMPER,U a b
MAIN X JR 0422 88-108-000-080 C-JUMPER,U a b
CSD-FD77 CSD-FD79
CSTC USTC
MAIN X JR 0433 88-108-000-080 C-JUMPER,U a b
MAIN X JR 0434 88-108-000-080 C-JUMPER,U a b
MAIN X JR 0601 88-129-000-080 C-JUMPER, 3216 a b
MAIN O L 0101 87-003-097-080 COIL,1.0UH K LAL02 a b
MAIN O L 0102 87-003-097-080 COIL,1.0UH K LAL02 a b
MAIN X L 0301 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MAIN O L 0331 87-007-342-010 COIL,OSC 85KHZ BIAS a b
MAIN O L 0410 87-003-097-080 COIL,1.0UH K LAL02 a .
MAIN S Q 0101 89-213-702-010 TR,2SB1370E a b
MAIN S Q 0102 87-A30-216-080 TR,2SA933AS(R) a b
MAIN S Q 0103 87-A30-623-080 TR,DTC124XSA a b
MAIN S Q 0104 89-213-702-010 TR,2SB1370E a b
MAIN S Q 0105 87-026-462-080 TR,2SC1740SRS a b
MAIN S Q 0243 87-026-610-080 TR,KTC3198GR a b
MAIN S Q 0244 87-026-610-080 TR,KTC3198GR a b
MAIN S Q 0311 89-110-155-080 TR,2SA1015GR a b
MAIN S Q 0312 89-110-155-080 TR,2SA1015GR a b
MAIN S Q 0320 87-026-610-080 TR,KTC3198GR a b
MAIN S Q 0331 87-026-610-080 TR,KTC3198GR a b
MAIN S Q 0332 87-026-610-080 TR,KTC3198GR a b
CSD-FD77 CSD-FD79
CSTC USTC
MAIN S Q 0333 87-026-610-080 TR,KTC3198GR a b
MAIN S Q 0335 86-NFZ-664-040 C-TR,DTC143TKA a b
MAIN S Q 0336 87-A30-435-040 C-TR,DTC144EKA a b
MAIN S Q 0341 89-110-155-080 TR,2SA1015GR a b
MAIN S Q 0342 89-110-155-080 TR,2SA1015GR a b
MAIN S Q 0343 89-110-155-080 TR,2SA1015GR a b
MAIN S Q 0344 87-A30-435-040 C-TR,DTC144EKA a b
MAIN S Q 0401 89-112-965-080 TR,2SA1296GR a b
MAIN S Q 0402 87-026-215-080 TR,DTC114YS a b
MAIN S Q 0407 87-026-610-080 TR,KTC3198GR a b
MAIN S Q 0408 87-026-609-080 TR,KTA1266GR a b
MAIN S Q 0409 87-026-609-080 TR,KTA1266GR a b
MAIN S Q 0498 87-A30-432-040 C-TR,DTC124XKA a b
MAIN S Q 0499 87-A30-432-040 C-TR,DTC124XKA a b
MAIN X R 0101 88-121-102-080 RES,1K-1/8W J a b
MAIN X R 0102 88-108-474-080 C-RES,U 470K-1/16W J a b
MAIN X R 0103 88-108-471-080 C-RES,U 470-1/16W J a b
MAIN O R 0104 88-108-103-080 C-RES,U 10K-1/16W J a b
MAIN X R 0105 88-108-152-080 C-RES,U 1.5K-1/16W J a b
MAIN O R 0106 88-108-101-080 C-RES,U 100-1/16W J a b
