Aiwa CSD-FD79 Service Manual

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-12-
ELECTRICAL PARTS LIST - 7/12 (CSD-FD79/77) - 7/10
CSD-FD77 CSD-FD79
CSTC USTC
MAIN X R 0357 88-108-222-080 C-RES,U 2.2K-1/16W J a b
MAIN X R 0358 88-108-222-080 C-RES,U 2.2K-1/16W J a b
MAIN X R 0359 88-108-681-080 C-RES,U 680-1/16W J a b
MAIN X R 0360 88-108-681-080 C-RES,U 680-1/16W J a b
MAIN X R 0361 88-108-333-080 C-RES,U 33K-1/16W J a b
MAIN X R 0362 88-108-333-080 C-RES,U 33K-1/16W J a b
MAIN O R 0363 88-108-822-080 C-RES,U 8.2K-1/16W J a b
MAIN O R 0364 88-108-822-080 C-RES,U 8.2K-1/16W J a b
MAIN X R 0367 88-108-682-080 C-RES,U 6.8K-1/16W J a b
MAIN X R 0368 88-108-682-080 C-RES,U 6.8K-1/16W J a b
MAIN X R 0381 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MAIN X R 0401 88-121-102-080 RES,1K-1/8W J a b
MAIN O R 0402 88-108-473-080 C-RES,U 47K-1/16W J a b
MAIN X R 0402 88-121-473-080 RES,47K-1/8W J a b
MAIN X R 0403 88-121-331-080 RES,330-1/8W J a b
MAIN X R 0416 88-108-221-080 C-RES,U 220-1/16W J a b
MAIN X R 0417 88-118-470-080 C-RES,S 47-1/10W J a b
MAIN X R 0418 88-118-100-080 C-RES,S 10-1/10W J a b
MAIN X R 0419 88-118-101-080 C-RES,S 100-1/10W J a b
MAIN X R 0420 88-118-152-080 C-RES,S 1.5K-1/10W J a b
CSD-FD77 CSD-FD79
CSTC USTC
MAIN X R 0421 88-118-152-080 C-RES,S 1.5K-1/10W J a b
MAIN X R 0422 88-118-102-080 C-RES,S 1K-1/10W J a b
MAIN X R 0423 88-121-101-080 RES,100-1/8W J a b
MAIN X R 0424 88-121-101-080 RES,100-1/8W J a b
MAIN X R 0425 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MAIN X R 0426 88-118-152-080 C-RES,S 1.5K-1/10W J a b
MAIN X R 0427 88-118-152-080 C-RES,S 1.5K-1/10W J a b
MAIN X R 0428 88-118-470-080 C-RES,S 47-1/10W J a b
MAIN O R 0429 88-108-103-080 C-RES,U 10K-1/16W J a b
MAIN O R 0430 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN O R 0431 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN O R 0432 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN O R 0433 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN O R 0434 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN O R 0435 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN O R 0436 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN X R 0437 88-108-681-080 C-RES,U 680-1/16W J a b
MAIN X R 0438 88-108-681-080 C-RES,U 680-1/16W J a b
MAIN O R 0439 88-108-123-080 C-RES,U 12K-1/16W J a b
MAIN X R 0440 88-108-122-080 C-RES,U 1.2K-1/16W J a b
CSD-FD77 CSD-FD79
CSTC USTC
MAIN O R 0441 88-108-103-080 C-RES,U 10K-1/16W J a b
MAIN X R 0442 88-108-273-080 C-RES,U 27K-1/16W J a b
MAIN X R 0443 88-108-331-080 C-RES,U 330-1/16W J a b
MAIN X R 0447 88-108-000-080 C-JUMPER,U a b
MAIN X R 0448 88-108-000-080 C-JUMPER,U a b
MAIN O R 0449 88-108-473-080 C-RES,U 47K-1/16W J a b
MAIN O R 0451 88-108-103-080 C-RES,U 10K-1/16W J a b
MAIN X R 0452 88-121-339-080 RES,3.3-1/8W J a b
MAIN X R 0453 88-108-333-080 C-RES,U 33K-1/16W J a b
MAIN X R 0454 88-108-183-080 C-RES,U 18K-1/16W J a b
MAIN X R 0455 88-108-183-080 C-RES,U 18K-1/16W J a b
MAIN X R 0456 88-108-183-080 C-RES,U 18K-1/16W J a b
MAIN X R 0457 88-108-183-080 C-RES,U 18K-1/16W J a b
MAIN X R 0458 88-108-333-080 C-RES,U 33K-1/16W J a b
MAIN X R 0459 88-108-181-080 C-RES,U 180-1/16W J a b
MAIN X R 0460 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MAIN X R 0461 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MAIN X R 0462 88-100-000-010 PLATING-JW, 0.58 SN95 a b
MAIN O R 0463 88-108-103-080 C-RES,U 10K-1/16W J a b
MAIN X R 0464 88-118-479-080 C-RES,S 4.7-1/10W J a b
CSD-FD77 CSD-FD79
CSTC USTC
MAIN X R 0465 88-118-101-080 C-RES,S 100-1/10W J a b
MAIN X R 0466 88-121-103-080 RES,10K-1/8W J a b
MAIN X R 0466 88-121-392-080 RES,3.9K-1/8W J a b
MAIN O R 0470 88-108-103-080 C-RES,U 10K-1/16W J a b
MAIN O R 0476 88-108-101-080 C-RES,U 100-1/16W J a b
MAIN O R 0477 88-108-101-080 C-RES,U 100-1/16W J a b
MAIN O R 0478 88-108-101-080 C-RES,U 100-1/16W J a b
MAIN O R 0479 88-108-101-080 C-RES,U 100-1/16W J a b
MAIN O R 0480 88-108-101-080 C-RES,U 100-1/16W J a b
MAIN O R 0481 88-108-101-080 C-RES,U 100-1/16W J a b
MAIN O R 0497 88-108-103-080 C-RES,U 10K-1/16W J a b
MAIN O R 0498 88-108-103-080 C-RES,U 10K-1/16W J a b
MAIN O R 0499 88-108-103-080 C-RES,U 10K-1/16W J a b
MAIN O SW 0401 87-036-389-010 SW,PUSH 1-1-1 R8120125 a b
MAIN O X 0401 81-592-641-010 VIB,CER 16.93MHZ a b
POWER O C 0701 87-018-205-080 CAP,TC U 0.022-25 Z F TP a b
POWER O C 0702 87-018-205-080 CAP,TC U 0.022-25 Z F TP a b
POWER O C 0703 87-018-205-080 CAP,TC U 0.022-25 Z F TP a b
POWER O C 0704 87-018-205-080 CAP,TC U 0.022-25 Z F TP a b
POWER O CNA0701 8C-CHE-661-010 CONN ASSY,3P POWER-MAIN a b
