! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-45-
MECHANISM PARTS LIST - 1/1 (AZM-6 YR3NC)
AZM-6
YR3NC
O ST1001 8Z-ZM3-216-310 LEVER,T-UP M3 a
O ST1002 8Z-ZM1-257-210 SPR-C,F/R a
O ST1003 8Z-ZM1-236-010 CLR,SLIP FF/REW a
O ST1004 8Z-ZM3-261-010 SPR-C,FR M3 C a
O ST1005 8Z-ZM3-250-010 GEAR,SLIP F/R A M3 a
O ST1006 8Z-ZM1-238-110 GEAR,SLIP FF/REW B 2 a
O ST1007 8Z-ZM3-263-010 SPR-E,FR C a
O ST1008 8Z-ZM3-220-110 LEVER,FR M3 a
O ST1009 8Z-ZM3-205-110 LEVER,PLAY M3 a
O ST1010 87-A90-404-110 HEAD,EH LE15B a
O ST1011 87-A92-373-010 HEAD,PH T21VLC a
O ST1012 8Z-ZM3-262-010 SPR-T,BRG M3 C a
O ST1013 8Z-ZM3-236-310 SPR-T,PLAY M3 a
O ST1014 8Z-ZM3-251-010 GEAR,IDL REW M3 a
O ST1015 8Z-ZM1-226-010 GEAR,REEL L a
O ST1016 8Z-ZM3-222-210 SPR-C,REEL L M3 a
O ST1017 82-ZM1-240-110 LVR,REC a
O ST1018 8Z-ZM3-234-310 SPR-T,LVR CAS a
O ST1019 8Z-ZM3-221-210 LEVER,CAS a
O ST1020 8A-ZM6-207-010 LEVER,STOP a
AZM-6
YR3NC
O ST1021 8Z-ZM1-225-110 GEAR,REEL R a
O ST1022 8Z-ZM3-223-310 SPR-C,REEL R M3 a
O ST1023 8Z-ZM3-215-110 LEVER,PINCH M3 a
O ST1024 8Z-ZM3-264-010 SPR-T,T-UP M3 C a
O ST1025 8A-ZM6-204-010 LEVER,EJECT a
O ST1026 8Z-ZM3-227-210 BELT,MAIN M3 a
O ST1027 8Z-ZM1-271-010 PULLEY,MOT ZZM-1 a
O ST1028 8A-ZM6-206-010 CLR,MG a
O ST1029 82-ZM3-616-010 RING MAGNET 4 a
O ST1030 8Z-ZM3-256-010 FLY-WHL ASSY,M3 R a
O ST1030a 8Z-ZM2-211-310 FLY-WHL,ZZM-2 a
O ST1030b 8Z-ZM3-242-110 SHAFT,CAP M3 a
O ST1031 8Z-ZM1-251-310 SPR-C,T-UP SLIP a
O ST1032 8Z-ZM1-227-010 GEAR,SLIP T-UP A a
O ST1033 8Z-ZM1-228-010 GEAR,SLIP T-UP B a
O ST1034 8Z-ZM1-232-010 GEAR,IDL FF/REW a
O ST1035 8Z-ZM3-229-010 GEAR,IDL M3 a
O ST1036 8Z-ZM3-219-310 GEAR,CAM M3 a
O ST1037 8Z-ZM3-209-010 LEVER,CAM FR a
O ST1038 8Z-ZM3-243-110 LEVER ASSY,HD UP a
AZM-6
YR3NC
X ST1038a 8Z-ZM3-207-010 LEVER,HD UP a
X ST1038b 8Z-ZM3-241-110 SHAFT,HD UP a
O ST1039 8Z-ZM3-238-110 SPR-T,HD UP a
O ST1040 82-ZM3-628-010 SOL ASSY,23 SO a
X ST1040a 82-ZM3-629-010 HLDR,BOBBIN SOL SO a
X ST1040b 82-ZM3-630-010 YOKE,SOL SO a
X ST1040c 82-ZM3-631-010 SHAFT,CORE SOL SO a
X ST1040d 82-ZM3-632-010 SHAFT,PLUNGER SOL SO a
X ST1040e 82-ZM3-633-010 TERMINAL,SOL SO a
X ST1040f 87-450-411-010 TERMINAL,LB 1 a
O ST1041 8Z-ZM3-206-010 LEVER,TRIG a
O ST1042 8Z-ZM3-231-310 SPR-T,TRIG a
O ST1043 8A-ZM6-201-210 CHAS ASSY,M6 a
X ST1043a 8Z-ZM1-268-010 BRG,METAL a
X ST1043b 8A-ZM6-202-210 CHAS ASSY,OUT-SERT M6 a
X ST1043c 8A-ZM6-203-010 CHAS,M6 a
O ST1044 84-ZM2-227-310 SPR-C,AZIMUTH a
O ST1045 8Z-ZM1-269-010 FELT,FF/REW 2 a
O ST1046 8Z-ZM1-265-010 FELT,T-UP a
O ST1047 8Z-ZM1-261-110 ROLLER ASSY,PINCH a
AZM-6
YR3NC
X ST1047a 8Z-ZM1-262-010 CLR,ROLLER a
X ST1047b 8Z-ZM1-263-010 ROLLER,PINCH a
O ST1048 8Z-ZM3-252-010 SPR-T,PINCH 2 a
O ST1049 8A-ZM6-205-010 HLDR,IC a
O ST1050 87-A92-349-010 MOT,SHE2L60 a
X ST1051 89-936-120-110 WIRE,UB6-12-3 a
X ST1052 8A-ZM6-602-010 PWB,MAIN M6 a
O ST1A 84-ZM2-252-010 S-SCREW,AZI-2-6.4 C a
O ST1B 8Z-ZM3-245-110 V+2.6 ZZM-3 a
O ST1C 87-B10-301-010 W-L,1.63-3.2-0.5 SLIT a
O ST1D 8Z-ZM1-275-010 W-L,1.47-4-0.25 a
