-4-
PRECAUTION TO REPALCE OPTICAL BLOCK (KSM-213 RDM) - 1/1
1)
After the connection, remove solder shown in
the right figure.
Body or clothes electrostatic potential could ruin
laser diode in the optical block. Be sure ground
body and workbench, and use care the clothes
do not touch the diode.
Solder
3
5
Table of Contents
Specifications
2
Protection of Eyes from Laser Beam During Servicing
3
Accessories Parts List
5
Electrical Parts List
18
Transistor Illustration
19
Electrical Adjustment
31
Digital Multimeter
31
Deck Adjustment
34
CD Test Mode
36
IC Block Diagram
37
Mechanical Exploded View
42
Mechanical Parts List
43
Color Name Table
45
