! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME S UFFIX&MODEL
-43-
MECHANICAL PARTS LIST - 1/2
CSD-FD89 CSD-FD89 CSD-FD89
LHSTC UCSTC USTC
O MC1001 8C-CHE-031-010 CABI ASSY,FR a . .
O MC1001 8C-CHE-011-010 CABI ASSY,FR U . b c
X MC1001a 8C-CHE-032-010 CABI,FR a . .
X MC1001a 8C-CHE-012-010 CABI,FR U . b c
X MC1001b 8C-CHE-013-010 GRILLE,SPKR L a b c
X MC1001c 8C-CHE-014-010 GRILLE,SPKR R a b c
X MC1002 8C-CHE-665-010 WIRE,FASTEN ASSY ANT a b c
X MC1003 8C-CHE-626-010 PWB,POWER LH 4.5W CCH-E a . .
X MC1003 8C-CHE-605-010 PWB,POWER 4.5W CCH-E . b c
O MC1004 8C-CHE-024-010 BTN,EQ a b c
O MC1005 8C-CHE-025-010 BTN,VOL a b c
O MC1006 8C-CHE-211-010 SPR-T,VOL a b c
O MC1007 8C-CHE-022-010 WINDOW,DISP a b c
X MC1008 8C-CHE-206-010 SH,LCD a b c
X MC1009 8C-CHE-201-010 LENS,LCD a b c
X MC1010 8C-CHE-202-010 HLDR,LCD a b c
X MC1011 8C-CHE-203-010 PLATE,SPKR L a b c
O MC1012 8B-CH4-640-010 SPKR,36MM FY36-1C-W/GASKET a b c
O MC1013 8C-CHE-026-010 BTN,POWER a b c
O MC1014 8C-CHE-039-010 BTN,FUNC LH a . .
CSD-FD89 CSD-FD89 CSD-FD89
LHSTC UCSTC USTC
O MC1014 8C-CHE-023-010 BTN,FUNC . b c
O MC1015 8C-CHE-027-010 BTN,REPEAT a b c
O MC1016 8C-CHE-028-010 RING,FUNC a b c
X MC1017 8C-CHE-204-010 PLATE,SPKR R a b c
O MC1018 8C-CHE-635-110 LCD,CCH-E/ADAMANT a b .
O MC1018 8C-CHE-632-010 LCD,CCH-E . . c
O MC1019 8B-CH4-203-010 HLDR,TU a b c
X MC1020 M8-AZM-695-070 AZM-6 YR3NC a b c
O MC1021 M8-CZK-490-070 KSM-213RDM a b c
O MC1022 87-036-389-010 SW,PUSH 1-1-1 R8120125 a b c
O MC1023 8C-CHE-207-010 PLATE,CASS SPR a b c
O MC1024 8C-CHE-034-010 CHAS,TOP a . .
O MC1024 8C-CHE-016-010 CHAS,TOP U . b c
O MC1025 82-NF5-229-010 PLATE,LOCK(*) a b c
O MC1026 8B-CH4-210-010 SPR-T,CASS a b c
O MC1027 8C-CHE-018-010 BOX,CASS a b c
O MC1028 8C-CHE-017-010 BOX,CD a b c
O MC1029 8B-CH4-211-010 SPR-T,CD a b c
O MC1030 8B-CH4-223-010 BASE,CHUCK N a b c
O MC1031 86-CT9-222-010 PLATE,MAGNET a b c
CSD-FD89 CSD-FD89 CSD-FD89
LHSTC UCSTC USTC
O MC1032 8C-CHE-220-010 MAGNET,CD F/M a b c
O MC1033 86-CD4-225-010 HLDR,CHUCK A a b c
O MC1034 8C-CHE-020-010 HANDL,ARM a b c
O MC1035 8C-CHE-021-010 HANDL,GRIP a b c
O MC1036 8B-CH4-042-010 PLATE,AC . b c
O MC1037 8C-CHE-019-010 LID,BATT a b c
O MC1038 8C-CHE-035-010 CABI,REAR LH a . .
O MC1038 8C-CHE-015-010 CABI,REAR U . b c
O MC1039 87-A92-151-010 ANT,ROD 5SEC709 a b c
O MC1040 87-A92-285-010 COVER,AC SOCKET COVER PSU27-MC a b c
O MC1041 8A-CDB-220-010 HLDR,M66 BAR ANT a b c
O MC1042 8A-CH4-670-010 BAR-ANT,MW 2B-ACH(COI) a b c
O MC1043 8B-CH4-221-010 SPR-C,BATT(-) a b c
O MC1044 8C-CHE-030-010 PLATE,BOX CASS a b c
O MC1045 8B-CH4-205-010 HLDR,PT a b c
X MC1046 8C-CHE-205-010 PLATE,SPKR CEN a b c
O MC1047 88-CH6-019-010 PANEL,CD a b c
X MC1048 8B-CH4-681-010 HT-SINK,MAIN4.5W BCH-4 a b c
O MC1049 8C-CHE-633-010 SPKR,100MM 3.2OHM 4.5W CCH-E a b c
O MC1050 8C-CHE-029-010 LENS,LED a b c
CSD-FD89 CSD-FD89 CSD-FD89
LHSTC UCSTC USTC
O MC1051 86-NF9-224-010 SPR-C,LOCK a b c
O MC1052 87-NF4-217-110 HLDR,LOCK 2 a b c
O MC1053 8C-CHE-212-010 HLDR,DAMP GEAR F/M a b c
O MC1054 8C-CHE-213-010 GEAR,OIL DAMP F/M a b c
X MC1055 8C-CHE-621-010 PWB,TU SYNTH 4M a b c
X MC1056 8C-CHE-611-010 PWB,FR 2M a b c
X MC1057 8C-CHE-628-010 PWB,COVER LH 4.5W CCH-E a . .
X MC1057 8C-CHE-607-010 PWB,COVER 4.5W CCH-E . b c
X MC1058 8C-CHE-629-010 PWB,TWTR LH 4.5W CCH-E a . .
X MC1058 8C-CHE-608-010 PWB,TWTR 4.5W CCH-E . b c
X MC1059 8C-CHE-627-010 PWB,BATT LH 4.5W CCH-E a . .
X MC1059 8C-CHE-606-010 PWB,BATT 4.5W CCH-E . b c
X MC1060 8C-CHE-623-010 PWB,MAIN LH 4.5W CCH-E a . .
X MC1060 8C-CHE-602-010 PWB,MAIN 4.5W CCH-E . b c
O MC1061 88-CH6-220-110 CUSHION,CD A a b .
O MC1061 8C-CHE-210-010 CUSH,CD F/M . . c
! O MC1062 8B-CT5-622-010 PT,H EI-57 a . .
! O MC1062 8B-CT5-620-010 PT,U EI-57 . b c
! O MC1063 87-A61-455-010 JACK,AC E PSE27 a . .
! O MC1063 87-A61-453-010 JACK,AC U PSU27-N . b c
