! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-9-
ELECTRICAL PARTS LIST - 4/13 (CSD-FD89) - 4/11
CSD-FD89 CSD-FD89 CSD-FD89
LHSTC UCSTC USTC
MAIN O C 0308 87-A11-228-080 C-CAP,U 0.027-25 K B a b c
MAIN O C 0311 87-010-546-080 CAP,E 0.33-50 M 11L SME a b c
MAIN O C 0312 87-010-546-080 CAP,E 0.33-50 M 11L SME a b c
MAIN O C 0313 87-012-283-080 C-CAP,U 5600P-50 K B GRM a b c
MAIN O C 0314 87-012-283-080 C-CAP,U 5600P-50 K B GRM a b c
MAIN O C 0321 87-018-205-080 CAP,TC U 0.022-25 Z F TP a b c
MAIN O C 0323 87-012-271-080 C-CAP,U 560P-50 K B GRM a b c
MAIN O C 0324 87-012-271-080 C-CAP,U 560P-50 K B GRM a b c
MAIN O C 0331 87-018-126-080 CAP,TC U 390P-50 K B UP050 a b c
MAIN O C 0332 87-018-126-080 CAP,TC U 390P-50 K B UP050 a b c
MAIN O C 0333 87-012-275-080 C-CAP,U 1200P-50 K B GRM a b c
MAIN O C 0334 87-012-278-080 C-CAP,U 2200P-50 K B GRM a b c
MAIN X C 0335 88-700-730-810 CAP,M 5600P-50 J AMZV a b c
MAIN O C 0336 87-018-134-080 CAP,TC U 0.01-16 N Y UP050 a b c
MAIN O C 0337 87-012-279-080 C-CAP,U 2700P-50 K B GRM a b c
MAIN O C 0338 87-012-279-080 C-CAP,U 2700P-50 K B GRM a b c
MAIN O C 0339 87-012-279-080 C-CAP,U 2700P-50 K B GRM a b c
MAIN O C 0340 87-A12-691-040 CAP,E 22-16 M 5L R85S5 a b c
MAIN O C 0345 87-012-274-080 C-CAP,U 1000P-50 K B GRM a b c
MAIN O C 0346 87-012-274-080 C-CAP,U 1000P-50 K B GRM a b c
CSD-FD89 CSD-FD89 CSD-FD89
LHSTC UCSTC USTC
MAIN O C 0347 87-010-374-080 CAP,E 47-10 M 11L SME a b c
MAIN O C 0348 87-012-274-080 C-CAP,U 1000P-50 K B GRM a b c
MAIN O C 0350 87-012-275-080 C-CAP,U 1200P-50 K B GRM a b c
MAIN O C 0351 87-012-278-080 C-CAP,U 2200P-50 K B GRM a b c
MAIN O C 0355 87-012-279-080 C-CAP,U 2700P-50 K B GRM a b c
MAIN O C 0356 87-012-279-080 C-CAP,U 2700P-50 K B GRM a b c
MAIN O C 0357 87-010-784-080 C-CAP,U 0.012-25 K B GRM a b c
MAIN O C 0358 87-010-784-080 C-CAP,U 0.012-25 K B GRM a b c
MAIN O C 0363 87-010-401-080 CAP,E 1-50 M 11L SME a b c
MAIN O C 0364 87-010-401-080 CAP,E 1-50 M 11L SME a b c
MAIN O C 0367 87-012-196-080 C-CAP,U 120P-50 J CH GRM a b c
MAIN O C 0368 87-012-196-080 C-CAP,U 120P-50 J CH GRM a b c
MAIN O C 0401 87-A11-132-080 CAP,TC U 0.01-50 K B a b c
MAIN O C 0402 87-A12-064-080 CAP,E 1000-10 SMG a b c
MAIN O C 0404 87-012-172-080 C-CAP,U 10P-50 D CH GRM a b c
MAIN O C 0405 87-012-169-080 C-CAP,U 7P-50 D CH GRM a b c
MAIN X C 0406 88-108-000-080 C-JUMPER,U a b c
MAIN O C 0407 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b c
MAIN O C 0408 87-010-263-080 CAP,E 100-10 M 11L SME a b c
MAIN O C 0409 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b c
CSD-FD89 CSD-FD89 CSD-FD89
LHSTC UCSTC USTC
MAIN O C 0410 87-010-260-080 CAP,E 47-25 M 11L SME a b c
MAIN O C 0411 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b c
MAIN O C 0412 87-010-405-080 CAP,E 10-50 M 11L SME a b c
MAIN O C 0413 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b c
MAIN O C 0414 87-010-263-080 CAP,E 100-10 M 11L SME a b c
MAIN O C 0415 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b c
MAIN O C 0416 87-010-403-080 CAP,E 3.3-50 M 11L SME a b c
MAIN O C 0417 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b c
MAIN O C 0418 87-A10-504-080 C-CAP,U 0.047-16 K B a b c
MAIN O C 0419 87-010-403-080 CAP,E 3.3-50 M 11L SME a b c
MAIN O C 0420 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b c
MAIN O C 0421 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b c
MAIN O C 0422 87-010-263-080 CAP,E 100-10 M 11L SME a b c
MAIN O C 0423 87-A10-504-080 C-CAP,U 0.047-16 K B a b c
MAIN O C 0424 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b c
MAIN O C 0425 87-012-188-080 C-CAP,U 47P-50 J CH GRM a b c
MAIN O C 0426 87-012-282-080 C-CAP,U 4700P-50 K B GRM a b c
MAIN O C 0427 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b c
MAIN O C 0428 87-010-263-080 CAP,E 100-10 M 11L SME a b c
MAIN O C 0429 87-010-263-080 CAP,E 100-10 M 11L SME a b c
CSD-FD89 CSD-FD89 CSD-FD89
LHSTC UCSTC USTC
MAIN O C 0430 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b c
MAIN O C 0431 87-010-263-080 CAP,E 100-10 M 11L SME a b c
MAIN O C 0432 87-010-405-080 CAP,E 10-50 M 11L SME a b c
MAIN O C 0433 87-010-545-080 CAP,E 0.22-50 M 11L SME a b c
MAIN O C 0434 87-012-188-080 C-CAP,U 47P-50 J CH GRM a b c
MAIN O C 0435 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b c
MAIN O C 0436 87-010-263-080 CAP,E 100-10 M 11L SME a b c
MAIN O C 0437 87-010-405-080 CAP,E 10-50 M 11L SME a b c
MAIN O C 0438 87-012-274-080 C-CAP,U 1000P-50 K B GRM a b c
MAIN O C 0439 87-010-263-080 CAP,E 100-10 M 11L SME a b c
MAIN O C 0440 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b c
MAIN O C 0441 87-010-263-080 CAP,E 100-10 M 11L SME a b c
MAIN O C 0442 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b c
MAIN O C 0443 87-010-376-090 CAP,E 2200-10 M SME a b .
MAIN O C 0443 87-010-112-080 CAP,E 100-16 M 11L SME . . c
MAIN O C 0444 87-A11-148-080 CAP,TC U 0.1-50 Z F a b c
MAIN O C 0445 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b c
MAIN O C 0446 87-010-263-080 CAP,E 100-10 M 11L SME a b c
MAIN O C 0451 87-012-195-080 C-CAP,U 100P-50 J CH GRM a b c
MAIN O C 0452 87-012-195-080 C-CAP,U 100P-50 J CH GRM a b c
