21
CX-VX5
3-13. LEVER (LOADING-R/L)
lever (loading-R)
Align the horizontal position.
lever (loading-L)
Install the
both levers so that they move symmetrically.
2
two hooks
4
two hooks
3
lever (loading-L)
5
lever (loading-R)
spr-T (loading-L) spr-T (loading-R)
1
1
PRECAUTION DURING LEVER (LOADING-R/L) INSTALLATION
