6
HDMI Standard Type A connector
Video:
8-bit RGB 4:4:4 or
10-bit YCbCr 4:2:2 (selectable by internal jumper)
Audio:
24-bit, with 2 or 8 embedded channels (selectable by
internal jumper)
HDCP The Hi5 does not encode the HDMI output with HDCP
encryption. By definition, SDI/HD-SDI inputs to the Hi5 are
unencrypted. The HDMI specification requires HDMI
monitors to support unencrypted inputs.
Size 4.6" x 2.4" x 1" (117mm x 61mm x 25mm.)
Power +5 VDC regulated, 3 watts
(AJA power supply required: model DWP or DWP-U)
