Panel User Interface
• 2 x 20 character display, with dedicated buttons
Timecode
• LTC timecode input and output via BNC
• SDI embedded RP188 timecode
• Onscreen timecode display on SDI 2 output
Serial Port
RS-422 (slave pinout), 9-pin (available beginning with version 2.0 firmware)—Connector
pinout is as follows:
:
Hardware Conversion
Up-conversion - 10-bit
Anamorphic: Full-screen
Pillar box 4:3: Results in a 4:3 image in center of screen with black sidebars
Zoom 14:9: Results in a 4:3 image zoomed slightly to fill a 14:9 image with black side bars
Zoom Letterbox: Image zoomed to fill screen
Zoom Wide: Combination of zoom and horizontal stretch to fill 16:9 screen; this setting can introduce
a small aspect ratio change
Down-conversion - 10-bit
Anamorphic: Full-screen
Letterbox: Image is reduced with black top and bottom added to image area with the aspect ratio
preserved
Crop: Image is cropped to fit new screen size
1GND
2TX -
3RX +
4GND
5 No Connection
6GND
7TX +
8RX -
9GND
Shell GND
