1：Front Diagram
No. Part Name Part Code Q'ty Remark
101 Cylinder B2H001 1 Body Up/Down
102 Air Joint C0C050 2
103 Cylinder B1C003 1 Front Clamp
104 Speed Controller C1A076 6
105 Knuckle Joint B6B001 1
106 Cylinder B1C012 2
Side Expander :
Left and Right
107 Knuckle Joint B6A008 2
108 Push Button Switch 21I111 1 Reset
109 Push Button Switch 21I148 1 Auto Start
110 Push Button Switch 21I151 1 Emergency
111 Dial 21D006 1
112 Foot Pedal Unit FP-UNT-023-1 3
113 Power Switch 21C006 1
114 Manifold Valve A0F159 1
Include from No.115 to No119.
115 Solenoid Valve A0E012 4
116 Solenoid Valve A0E013 1
117 Silencer C0A003 4
118 Air Joint C0C018 1
119 Air Joint C0C016 1
120 Air Joint C1A084 3
REV: 0
To Next Page
