AJAX FireProtect User Manual


Indication
Event
Indication
Detector switching on
The logo lights up green for 1 second
Detector switching off
The logo blinks red three times and the device
switches off
Registration failed
The logo blinks green for a minute, then the
device switches to the autonomous mode
Smoke or temperature increase detected
The siren switches on, the logo lights red during
the �re/smoke alarm
Battery low
Performance testing

One short sound signal per 90 sec — main
batteries low (CR2)
Two short sound signals per 90 sec — backup
battery low (CR2032)
Three short sound signals per 90 sec — both
batteries low

AJAX FireProtect Specifications

General

Battery Life	Up to 4 years
Dimensions	132 × 132 × 31 mm
Weight	220 g
Jeweller Technology	Yes
Tamper Protection	Yes
Hush Function	Yes
Interconnected Alarm	Yes
Humidity Range	Up to 80%
Power Supply	Two CR2 batteries
Installation Method	Ceiling mount
Communication Range with Hub	Up to 1, 300 m in open space
Alarm Volume	85 dB
Certification	EN 14604
Connectivity	Wireless
