AJAX FireProtect User Manual

Temperature sensitive element
Thermocouple
Sound noti�cation volume
85 dB at a distance of 3 m
Alarm threshold at the temperature
+59°С ±2°С
Tamper protection
Yes
Frequency band
868.0 – 868.6 MHz or 868.7 – 869.2 MHz
depending on the region of sale
Compatibility
Operates independently or with all Ajax
,
,
,
Maximum RF output power
Up to 20 mW
Radio signal modulation
GFSK
Radio signal range
Up to 1,300 m (any obstacles absent)
Power supply
2 × CR2 (main batteries), CR2032 (backup
battery), 3 V
hubs
range extenders
ocBridge Plus
uartBridge
Learn more

AJAX FireProtect Specifications

General

Battery Life	Up to 4 years
Dimensions	132 × 132 × 31 mm
Weight	220 g
Jeweller Technology	Yes
Tamper Protection	Yes
Hush Function	Yes
Interconnected Alarm	Yes
Humidity Range	Up to 80%
Power Supply	Two CR2 batteries
Installation Method	Ceiling mount
Communication Range with Hub	Up to 1, 300 m in open space
Alarm Volume	85 dB
Certification	EN 14604
Connectivity	Wireless
