AJAX Systems Inc.,
www.ajax.systems
support@ajax.systems
IMPORTANT!
Be careful when installing the fastening panel. Excessive force during its
fixation may lead to deformation and, as a consequence, the impossibility to
install a siren or insecure fixing. Secure fastening panel only with supplied
mounting tools! Use of other fasteners, such as screws of larger diameter
may result in fastening panel damage.
Do not use double-sided tape to secure siren! The tape eventually dries out
and loses its properties. It may cause siren’s fall, what will not allow it to
perform its function and can result in damage to the device
IMPORTANT!
When working outdoor or in unheated premises, if ambient temperature
is below zero degrees Celsius, the battery level may be reduced by a few
percent. This is due to temperature reaction of chemical components
of lithium batteries. Siren battery life depends on batteries quality and
frequency of the siren alarms. At the average battery works for about 3
years. In light and sound alarm mode new batteries charge is sufficient for
continuous siren sound at full volume for approximately 2 hours.
IMPORTANT!
By default, the siren is not activated when it’s accelerometer detects
movement (dismount alarm), because it is very likely that device will be
installed and removed during installation several times. To activate siren’s
dismount alarm, you need to specify appropriate option (Alert if Moved) in the
siren settings using mobile application or web browser. Apply these settings
only after final siren installation!
Built-in accelerometer needs about a minute to stabilize the position!
Therefore, to check alarm operation when you try to remove it is possible not
earlier than one minute after the final siren installation!
During siren body opening the alarm is always generated and it is impossible
to disable it in the siren settings! When removing back cover of the siren to
replace the batteries, first switch off the siren with power button ‘1’ (PICTURE
1), holding it for 3 seconds. When you switching off the siren, it will switch on
light ring for 1 second, then quickly blink 3 times and then will be switched
off. In armed mode when you try to remove or open the siren alarm (light and
sound) is generated immediately! Sirens’ light and sound alarm operating
time (from 3 seconds to 3 minutes) is configured in a mobile application or
a web browser.
5.5. Put the siren on SmartBracket, firmly attaching it to the fastener and
turning it clockwise. The siren is installed!
1 – tamper button
2 – siren’s buzzer
3 – СR123А batteries
4 – antenna
PICTURE 3. Battery compartment
8.2 Replace batteries with new in time! When battery discharges, the siren
transmits the “battery low” signal to the Hub. Also, when the batteries are low,
arming or disarming is accompanied by siren’s LED light one-time activation
and smooth dimming.
6. WORK INDICATION
6.1 When the siren is in armed mode, it signals about it by LED light «6»
(PICTURE 1), briefly blinking every 30 seconds. By default, blinking is off; you
can enable it in the siren settings using mobile application or browser.
6.2 If a siren is connected to a 12V wire power supply, in case of a stationary
power loss the siren will automatically start working on batteries. At this
moment alert about stationary power loss is coming to mobile application.
LED indication on stationary power supply loss is not performed not to
discharge the batteries.
6.3 When switching on armed mode the siren briefly beeps once and light ring
blinks for 1 second. When switching to disarmed mode the siren briefly beeps
twice and blinks with light ring twice. This feature is switched off by default.
7. VOLUME SETTING
7.1 Siren volume can be adjusted in the siren settings through a mobile
application or a web browser. Volume slider allows to change the siren volume
from 85 dB to 113 dB.
7.2 To check siren volume it is recommended to set sounding time to a
minimum (3 sec) and press keyfob’s alarm button.
8. MAINTENANCE
8.1 Once in 6 months clean the siren body from dust, cobwebs and other
possible contaminants.
9. WARRANTY
9.1 The warranty period for the siren is 24 months. Warranty does not apply
to the batteries!
1
2
3
3
4
To replace the batteries first disable the “Alert if Moved” option in siren
settings, then remove siren and switch it off by holding the power button for
3 seconds. Then unscrew 4 screws on the back side of the body and remove
top cover of the siren. Change 4 batteries (PICTURE 3) to new (CR123A type),
following polarity. After replacing batteries, test the siren operability!
